New CPU - new product RB750Gr3 - RB750G family - now mmips

It looks like the RB750Gr2 is now EOL. Our latest Mikrotik shipment arrived and we received a new part # RB750Gr3. This is the 4th major revision in the RB750G family since it was announced in 2009.

October 2009 - RB750G
May 2011 - RB750GL
July 2015 - RB750Gr2 aka hEX
October 2016 - RB750Gr3 aka hEX

There is no RB750Gr3 data sheet available yet. A quick comparison looking with winbox shows:

RB750Gr2
CPU - MIPS 74Kc V5.0 720MHz Single Core
RouterOS Family MIPSBE (supported for the past 8 years - many products)
RAM - 64MB
Flash - 16MB

RB750Gr3
CPU - MIPS 1004Kc V2.15 880MHz (Quad Core - depth of multicore support not yet known)
RouterOS Family MMIPS (new as of RB750Gr3)
RAM - 256MB
Flash - 16MB
external micro SD slot and card support

RB750Gr3 ships with RouterOS version 6.36.1. The CPU is also a new MIPS variant (mmips) that just gained Mikrotik support so older RouterOS versions will not work with this model router. (mmips was just added to the RouterOS download section today.)

Enjoy,

Tom

Wow, 720MHz single core to 880MHz quad core seems like a huge boost for a “revision”. Very curious how this translates into real world performance.

I see announcement on Russia MUM here is ti https://youtu.be/NjDdq3O6VoM?t=1339 before couple days.
Look the video they have on slide speed test.

It is nice info. Why mikrotik don´t say anything?
Latest news - Issue 72, May 2016 :confused:

What is the CPU in this device? Does it support hardware encryption for ipsec?

The CPU spec seems to line up with MediaTek MIPS 1004KeC processors. Maybe MMIPS is short for MediaTek MIPS ???

IF it is MediaTek then it has hardware crypto with support for up to 200mbit/s crypto acceleration.

It is the CPU MT7621A

This CPU support HW encryption. With AES-128 and 1400byte packets we were able to get 472Mbps Max.

Very impressive.

Nice work guys :slight_smile:

Thanks Normis.

So it is dual core and not quad core? Wondering why system/resources shows 4 cpus.

Please tell us more.

What is the product name for this device?

RB750Gr3 or hEX

Ok I see that hEX is RB750Gr2… a little confusing, those marketing names, especially when there is
no 1:1 mapping between marketing names and technical names. Would it not be better to call it
“hEX plus” or something?

By they way here are the slides about hEXr3 from MikroTik opening presentation, it contains some test results.
http://www.mikrotik.com/download/share/hexr3.pdf

When you look at the cars - “BMW 320” marketing name also remains unchanged during the years, just car is different :slight_smile:, and have different production code. Same happens here with “hEX”, it avoid lots of confusion about what to choose when old ones run out of the stock - sticking to same marketing name also gives a little bit easier time at customs and certifications, as you always can refer to previous model.

Wonder if this will be used for the Hap series as well.

I hope it makes it into the hAP and wAP product’s. :slight_smile:

Of course it replaces it by the confusion what we will receive when we order hEX from a local supplier, and the complaints here that older firmware
that people have validated for use on their network cannot be used on newly ordered hEX routers.
(of course that already happened even when there was no drastic change in model…)

Well, it looks like an interesting router but we will probably have to wait a while before we can safely order it (without risk of getting a Gr2 instead)

Buy from roc-noc.com as he is the original poster it is pretty certain that he sold all Gr2 out already :slight_smile:

I’d really like to buy this, but using the same model name is very annoying when you have to deal with distributors who aren’t aware of this or co-mingle their inventory. Same deal with the RB850Gx2, one version has HW encryption, one does not, but it’s impossible to tell from model name. It may be a long time before our local distributors sell out the RB750Gr2 stock, so I have no way of ordering one other than simply waiting and hoping their stock runs out :frowning:.
