Greetings folks,
I recently purchased a few mikrotik routers and am trying to teach myself about static routing. Basically i have three routers, daisy chained IN SERIES (eth2 in, eth3 out) between two laptops. Im trying to figure out how to manually set the routing tables so i can have the laptops communicate across the routers. Please see the attached picture for a schematic of the layout.
I am not able to 'see out' past eth2 on router 1 (starting from laptop 1).
Here is an outline of the settings i have in place:
Laptop 1
Static IP 192.168.88.4
gateway 192.168.88.1
subnet 255.255.255.0
Mikrotik RB2011ViAS-2HnD-IN || "Router 1" - designated 192.168.88.1
/ip address
add address 192.168.88.2/24 interface=ether2
add address 192.168.89.1/24 interface=ether3
/ip route
add dst-address 192.168.90.0/24 gateway 192.168.89.2
add dst-address 192.168.91.0/24 gateway 192.168.90.2
Mikrotik RB2011ViAS-2HnD-IN || "Router 2" - designated 192.168.89.1
/ip address
add address 192.168.89.2/24 interface=ether2
add address 192.168.90.1/24 interface=ether3
/ip route
add dst-address 192.168.88.0/24 gateway=192.168.89.1
add dst-address 192.168.91.0/24 gateway=192.168.90.2
Mikrotik CRS109-8G-1S-2HnD-IN || "Router 3" - designated 192.168.90.1
/ip address
add address 192.168.90.2/24 interface=ether2
add address 192.168.91.1/24 interface=ether3
/ip route
add dst-address 192.168.89.0/24 gateway=192.168.90.1
add dst-address 192.168.88.0/24 gateway=192.168.89.1
I have attempted to follow these resources: (but have found myself lost)
All routers are running WebFig v6.10, Laptop 1 is Win7, laptop 2 is Winxp.
What am i doing wrong here? Should i just factory reset and have a go at it all over again?
Thanks for your time!
Glokem!
