hi pukkita,
hi everyone other
thanks for informations, i’ve changed the values on the dictionary, sql database and post-proxy file
huber@maier.de
it is the same like… john@doe.com it’s my testuser
my testuser is in the filter group (well radius tells proper VLANID)
filter group settings on sql DB @ radgroupreply
+----+------------+-------------------------------+----+-------+
| id | groupname | attribute | op | value |
+----+------------+-------------------------------+----+-------+
| 1 | filter | Mikrotik_Wireless_VLANID | := | 0x14 |
| 2 | filter | Mikrotik_Wireless_VLANIDtype | := | 0x0 |
+----+------------+-------------------------------+----+-------+
freeradius -X output
(287) Received Access-Request Id 180 from 198.51.100.34:1814 to 198.51.100.35:1812 length 203
(287) Service-Type = Framed-User
(287) Framed-MTU = 1400
(287) User-Name = "huber@maier.de"
(287) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(287) NAS-Port-Type = Wireless-802.11
(287) Acct-Session-Id = "8210066c"
(287) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(287) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(287) EAP-Message = 0x02010013016875626572406d616965722e6465
(287) Message-Authenticator = 0xd20d50b03a226a33428f53bce169f985
(287) NAS-Identifier = "CAPsMAN"
(287) NAS-IP-Address = 198.51.100.33
(287) Proxy-State = 0x323430
(287) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(287) authorize {
(287) policy filter_username {
(287) if (&User-Name) {
(287) if (&User-Name) -> TRUE
(287) if (&User-Name) {
(287) if (&User-Name =~ / /) {
(287) if (&User-Name =~ / /) -> FALSE
(287) if (&User-Name =~ /@[^@]*@/ ) {
(287) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(287) if (&User-Name =~ /\.\./ ) {
(287) if (&User-Name =~ /\.\./ ) -> FALSE
(287) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(287) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(287) if (&User-Name =~ /\.$/) {
(287) if (&User-Name =~ /\.$/) -> FALSE
(287) if (&User-Name =~ /@\./) {
(287) if (&User-Name =~ /@\./) -> FALSE
(287) } # if (&User-Name) = notfound
(287) } # policy filter_username = notfound
(287) [preprocess] = ok
(287) [chap] = noop
(287) [mschap] = noop
(287) [digest] = noop
(287) suffix: Checking for suffix after "@"
(287) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(287) suffix: No such realm "maier.de"
(287) [suffix] = noop
(287) eap: Peer sent EAP Response (code 2) ID 1 length 19
(287) eap: EAP-Identity reply, returning 'ok' so we can short-circuit the rest of authorize
(287) [eap] = ok
(287) } # authorize = ok
(287) Found Auth-Type = eap
(287) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(287) authenticate {
(287) eap: Peer sent packet with method EAP Identity (1)
(287) eap: Calling submodule eap_peap to process data
(287) eap_peap: Initiating new EAP-TLS session
(287) eap_peap: [eaptls start] = request
(287) eap: Sending EAP Request (code 1) ID 2 length 6
(287) eap: EAP session adding &reply:State = 0xc1bb6d52c1b974cd
(287) [eap] = handled
(287) } # authenticate = handled
(287) Using Post-Auth-Type Challenge
(287) Post-Auth-Type sub-section not found. Ignoring.
(287) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(287) Sent Access-Challenge Id 180 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(287) EAP-Message = 0x010200061920
(287) Message-Authenticator = 0x00000000000000000000000000000000
(287) State = 0xc1bb6d52c1b974cd71f70b1b63d2de6d
(287) Proxy-State = 0x323430
(287) Finished request
Waking up in 4.9 seconds.
(288) Received Access-Request Id 55 from 198.51.100.34:1814 to 198.51.100.35:1812 length 315
(288) Service-Type = Framed-User
(288) Framed-MTU = 1400
(288) User-Name = "huber@maier.de"
(288) State = 0xc1bb6d52c1b974cd71f70b1b63d2de6d
(288) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(288) NAS-Port-Type = Wireless-802.11
(288) Acct-Session-Id = "8210066c"
(288) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(288) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(288) EAP-Message = 0x0202007119800000006716030100620100005e030158c4b5d9c5b21146e2f5a37450b85f73a5d347667ddaf99d6fe35c88cb6bc0a200001cc014c013003900330035002fc00ac00900380032000a00130005000401000019000a0006000400170018000b0002010000170000ff01000100
(288) Message-Authenticator = 0x936e50e37e45e65c4800819cc8a74f5d
(288) NAS-Identifier = "CAPsMAN"
(288) NAS-IP-Address = 198.51.100.33
(288) Proxy-State = 0x323431
(288) session-state: No cached attributes
(288) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(288) authorize {
(288) policy filter_username {
(288) if (&User-Name) {
(288) if (&User-Name) -> TRUE
(288) if (&User-Name) {
(288) if (&User-Name =~ / /) {
(288) if (&User-Name =~ / /) -> FALSE
(288) if (&User-Name =~ /@[^@]*@/ ) {
(288) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(288) if (&User-Name =~ /\.\./ ) {
(288) if (&User-Name =~ /\.\./ ) -> FALSE
(288) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(288) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(288) if (&User-Name =~ /\.$/) {
(288) if (&User-Name =~ /\.$/) -> FALSE
(288) if (&User-Name =~ /@\./) {
(288) if (&User-Name =~ /@\./) -> FALSE
(288) } # if (&User-Name) = notfound
(288) } # policy filter_username = notfound
(288) [preprocess] = ok
(288) [chap] = noop
(288) [mschap] = noop
(288) [digest] = noop
(288) suffix: Checking for suffix after "@"
(288) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(288) suffix: No such realm "maier.de"
(288) [suffix] = noop
(288) eap: Peer sent EAP Response (code 2) ID 2 length 113
(288) eap: Continuing tunnel setup
(288) [eap] = ok
(288) } # authorize = ok
(288) Found Auth-Type = eap
(288) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(288) authenticate {
(288) eap: Expiring EAP session with state 0xc1bb6d52c1b974cd
(288) eap: Finished EAP session with state 0xc1bb6d52c1b974cd
(288) eap: Previous EAP request found for state 0xc1bb6d52c1b974cd, released from the list
(288) eap: Peer sent packet with method EAP PEAP (25)
(288) eap: Calling submodule eap_peap to process data
(288) eap_peap: Continuing EAP-TLS
(288) eap_peap: Peer indicated complete TLS record size will be 103 bytes
(288) eap_peap: Got complete TLS record (103 bytes)
(288) eap_peap: [eaptls verify] = length included
(288) eap_peap: (other): before SSL initialization
(288) eap_peap: TLS_accept: before SSL initialization
(288) eap_peap: TLS_accept: before SSL initialization
(288) eap_peap: <<< recv TLS 1.2 [length 0062]
(288) eap_peap: TLS_accept: SSLv3/TLS read client hello
(288) eap_peap: >>> send TLS 1.0 Handshake [length 005d], ServerHello
(288) eap_peap: TLS_accept: SSLv3/TLS write server hello
(288) eap_peap: >>> send TLS 1.0 Handshake [length 0c00], Certificate
(288) eap_peap: TLS_accept: SSLv3/TLS write certificate
(288) eap_peap: >>> send TLS 1.0 Handshake [length 014b], ServerKeyExchange
(288) eap_peap: TLS_accept: SSLv3/TLS write key exchange
(288) eap_peap: >>> send TLS 1.0 Handshake [length 0004], ServerHelloDone
(288) eap_peap: TLS_accept: SSLv3/TLS write server done
(288) eap_peap: TLS_accept: Need to read more data: SSLv3/TLS write server done
(288) eap_peap: In SSL Handshake Phase
(288) eap_peap: In SSL Accept mode
(288) eap_peap: [eaptls process] = handled
(288) eap: Sending EAP Request (code 1) ID 3 length 1004
(288) eap: EAP session adding &reply:State = 0xc1bb6d52c0b874cd
(288) [eap] = handled
(288) } # authenticate = handled
(288) Using Post-Auth-Type Challenge
(288) Post-Auth-Type sub-section not found. Ignoring.
(288) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(288) Sent Access-Challenge Id 55 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(288) EAP-Message = 0x010303ec19c000000dc0160301005d02000059030105ce231e2ab32150a342f7a6e9015024385fd97b68c2cc5083888678317d798f2038af41516247bd0f9e27b3e091fcc6da1696efd86eb8944f7694a973b9f2afa8c014000011ff01000100000b000403000102001700001603010c000b000bfc000b
(288) Message-Authenticator = 0x00000000000000000000000000000000
(288) State = 0xc1bb6d52c0b874cd71f70b1b63d2de6d
(288) Proxy-State = 0x323431
(288) Finished request
Waking up in 4.8 seconds.
(289) Received Access-Request Id 240 from 198.51.100.34:1814 to 198.51.100.35:1812 length 208
(289) Service-Type = Framed-User
(289) Framed-MTU = 1400
(289) User-Name = "huber@maier.de"
(289) State = 0xc1bb6d52c0b874cd71f70b1b63d2de6d
(289) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(289) NAS-Port-Type = Wireless-802.11
(289) Acct-Session-Id = "8210066c"
(289) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(289) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(289) EAP-Message = 0x020300061900
(289) Message-Authenticator = 0xed5c185f1da6c8b200ebfae8ef9de1ca
(289) NAS-Identifier = "CAPsMAN"
(289) NAS-IP-Address = 198.51.100.33
(289) Proxy-State = 0x323432
(289) session-state: No cached attributes
(289) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(289) authorize {
(289) policy filter_username {
(289) if (&User-Name) {
(289) if (&User-Name) -> TRUE
(289) if (&User-Name) {
(289) if (&User-Name =~ / /) {
(289) if (&User-Name =~ / /) -> FALSE
(289) if (&User-Name =~ /@[^@]*@/ ) {
(289) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(289) if (&User-Name =~ /\.\./ ) {
(289) if (&User-Name =~ /\.\./ ) -> FALSE
(289) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(289) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(289) if (&User-Name =~ /\.$/) {
(289) if (&User-Name =~ /\.$/) -> FALSE
(289) if (&User-Name =~ /@\./) {
(289) if (&User-Name =~ /@\./) -> FALSE
(289) } # if (&User-Name) = notfound
(289) } # policy filter_username = notfound
(289) [preprocess] = ok
(289) [chap] = noop
(289) [mschap] = noop
(289) [digest] = noop
(289) suffix: Checking for suffix after "@"
(289) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(289) suffix: No such realm "maier.de"
(289) [suffix] = noop
(289) eap: Peer sent EAP Response (code 2) ID 3 length 6
(289) eap: Continuing tunnel setup
(289) [eap] = ok
(289) } # authorize = ok
(289) Found Auth-Type = eap
(289) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(289) authenticate {
(289) eap: Expiring EAP session with state 0xc1bb6d52c0b874cd
(289) eap: Finished EAP session with state 0xc1bb6d52c0b874cd
(289) eap: Previous EAP request found for state 0xc1bb6d52c0b874cd, released from the list
(289) eap: Peer sent packet with method EAP PEAP (25)
(289) eap: Calling submodule eap_peap to process data
(289) eap_peap: Continuing EAP-TLS
(289) eap_peap: Peer ACKed our handshake fragment
(289) eap_peap: [eaptls verify] = request
(289) eap_peap: [eaptls process] = handled
(289) eap: Sending EAP Request (code 1) ID 4 length 1000
(289) eap: EAP session adding &reply:State = 0xc1bb6d52c3bf74cd
(289) [eap] = handled
(289) } # authenticate = handled
(289) Using Post-Auth-Type Challenge
(289) Post-Auth-Type sub-section not found. Ignoring.
(289) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(289) Sent Access-Challenge Id 240 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(289) EAP-Message = 0x010403e8194074696e672e646530230603551d12041c301a8618687474703a2f2f7777772e737461727473736c2e636f6d2f30510603551d20044a30483008060667810c010201303c060b2b0601040181b537010205302d302b06082b06010505070201161f68747470733a2f2f7777772e7374617274
(289) Message-Authenticator = 0x00000000000000000000000000000000
(289) State = 0xc1bb6d52c3bf74cd71f70b1b63d2de6d
(289) Proxy-State = 0x323432
(289) Finished request
Waking up in 4.7 seconds.
(290) Received Access-Request Id 39 from 198.51.100.34:1814 to 198.51.100.35:1812 length 208
(290) Service-Type = Framed-User
(290) Framed-MTU = 1400
(290) User-Name = "huber@maier.de"
(290) State = 0xc1bb6d52c3bf74cd71f70b1b63d2de6d
(290) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(290) NAS-Port-Type = Wireless-802.11
(290) Acct-Session-Id = "8210066c"
(290) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(290) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(290) EAP-Message = 0x020400061900
(290) Message-Authenticator = 0xf574554d83dbb84380ba97bfc058812b
(290) NAS-Identifier = "CAPsMAN"
(290) NAS-IP-Address = 198.51.100.33
(290) Proxy-State = 0x323433
(290) session-state: No cached attributes
(290) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(290) authorize {
(290) policy filter_username {
(290) if (&User-Name) {
(290) if (&User-Name) -> TRUE
(290) if (&User-Name) {
(290) if (&User-Name =~ / /) {
(290) if (&User-Name =~ / /) -> FALSE
(290) if (&User-Name =~ /@[^@]*@/ ) {
(290) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(290) if (&User-Name =~ /\.\./ ) {
(290) if (&User-Name =~ /\.\./ ) -> FALSE
(290) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(290) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(290) if (&User-Name =~ /\.$/) {
(290) if (&User-Name =~ /\.$/) -> FALSE
(290) if (&User-Name =~ /@\./) {
(290) if (&User-Name =~ /@\./) -> FALSE
(290) } # if (&User-Name) = notfound
(290) } # policy filter_username = notfound
(290) [preprocess] = ok
(290) [chap] = noop
(290) [mschap] = noop
(290) [digest] = noop
(290) suffix: Checking for suffix after "@"
(290) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(290) suffix: No such realm "maier.de"
(290) [suffix] = noop
(290) eap: Peer sent EAP Response (code 2) ID 4 length 6
(290) eap: Continuing tunnel setup
(290) [eap] = ok
(290) } # authorize = ok
(290) Found Auth-Type = eap
(290) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(290) authenticate {
(290) eap: Expiring EAP session with state 0xc1bb6d52c3bf74cd
(290) eap: Finished EAP session with state 0xc1bb6d52c3bf74cd
(290) eap: Previous EAP request found for state 0xc1bb6d52c3bf74cd, released from the list
(290) eap: Peer sent packet with method EAP PEAP (25)
(290) eap: Calling submodule eap_peap to process data
(290) eap_peap: Continuing EAP-TLS
(290) eap_peap: Peer ACKed our handshake fragment
(290) eap_peap: [eaptls verify] = request
(290) eap_peap: [eaptls process] = handled
(290) eap: Sending EAP Request (code 1) ID 5 length 1000
(290) eap: EAP session adding &reply:State = 0xc1bb6d52c2be74cd
(290) [eap] = handled
(290) } # authenticate = handled
(290) Using Post-Auth-Type Challenge
(290) Post-Auth-Type sub-section not found. Ignoring.
(290) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(290) Sent Access-Challenge Id 39 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(290) EAP-Message = 0x010503e819404130820122300d06092a864886f70d01010105000382010f003082010a0282010100daecf4aa88678bb04b626696bfc94468e6c22b4ca033ceac79e376c3d156e075af41b40a4580efcb8de416e326143e111e41e7d4c93bb228d7909fc5f0d1fee538db8a7b3bb4520265777e41ed8e0c
(290) Message-Authenticator = 0x00000000000000000000000000000000
(290) State = 0xc1bb6d52c2be74cd71f70b1b63d2de6d
(290) Proxy-State = 0x323433
(290) Finished request
Waking up in 4.5 seconds.
(291) Received Access-Request Id 162 from 198.51.100.34:1814 to 198.51.100.35:1812 length 208
(291) Service-Type = Framed-User
(291) Framed-MTU = 1400
(291) User-Name = "huber@maier.de"
(291) State = 0xc1bb6d52c2be74cd71f70b1b63d2de6d
(291) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(291) NAS-Port-Type = Wireless-802.11
(291) Acct-Session-Id = "8210066c"
(291) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(291) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(291) EAP-Message = 0x020500061900
(291) Message-Authenticator = 0x8681d80a1eeba631a59716bab8a0aae2
(291) NAS-Identifier = "CAPsMAN"
(291) NAS-IP-Address = 198.51.100.33
(291) Proxy-State = 0x323434
(291) session-state: No cached attributes
(291) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(291) authorize {
(291) policy filter_username {
(291) if (&User-Name) {
(291) if (&User-Name) -> TRUE
(291) if (&User-Name) {
(291) if (&User-Name =~ / /) {
(291) if (&User-Name =~ / /) -> FALSE
(291) if (&User-Name =~ /@[^@]*@/ ) {
(291) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(291) if (&User-Name =~ /\.\./ ) {
(291) if (&User-Name =~ /\.\./ ) -> FALSE
(291) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(291) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(291) if (&User-Name =~ /\.$/) {
(291) if (&User-Name =~ /\.$/) -> FALSE
(291) if (&User-Name =~ /@\./) {
(291) if (&User-Name =~ /@\./) -> FALSE
(291) } # if (&User-Name) = notfound
(291) } # policy filter_username = notfound
(291) [preprocess] = ok
(291) [chap] = noop
(291) [mschap] = noop
(291) [digest] = noop
(291) suffix: Checking for suffix after "@"
(291) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(291) suffix: No such realm "maier.de"
(291) [suffix] = noop
(291) eap: Peer sent EAP Response (code 2) ID 5 length 6
(291) eap: Continuing tunnel setup
(291) [eap] = ok
(291) } # authorize = ok
(291) Found Auth-Type = eap
(291) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(291) authenticate {
(291) eap: Expiring EAP session with state 0xc1bb6d52c2be74cd
(291) eap: Finished EAP session with state 0xc1bb6d52c2be74cd
(291) eap: Previous EAP request found for state 0xc1bb6d52c2be74cd, released from the list
(291) eap: Peer sent packet with method EAP PEAP (25)
(291) eap: Calling submodule eap_peap to process data
(291) eap_peap: Continuing EAP-TLS
(291) eap_peap: Peer ACKed our handshake fragment
(291) eap_peap: [eaptls verify] = request
(291) eap_peap: [eaptls process] = handled
(291) eap: Sending EAP Request (code 1) ID 6 length 544
(291) eap: EAP session adding &reply:State = 0xc1bb6d52c5bd74cd
(291) [eap] = handled
(291) } # authenticate = handled
(291) Using Post-Auth-Type Challenge
(291) Post-Auth-Type sub-section not found. Ignoring.
(291) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(291) Sent Access-Challenge Id 162 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(291) EAP-Message = 0x010602201900d4148a8f1519b5dec1a89df1d65bc3da36deed62aaceeb196ed3e1160ac30ec81dc36ef342890d60165969ad4bc1864666075d88070b718922946a1b036c0b2a4e9e633e959dab43748e1a431e859075af294d1eeecfdc5329ba3f1def5eb0b8cfac28033b42f7c5daa2b3ced2990bef73
(291) Message-Authenticator = 0x00000000000000000000000000000000
(291) State = 0xc1bb6d52c5bd74cd71f70b1b63d2de6d
(291) Proxy-State = 0x323434
(291) Finished request
Waking up in 4.4 seconds.
(292) Received Access-Request Id 127 from 198.51.100.34:1814 to 198.51.100.35:1812 length 346
(292) Service-Type = Framed-User
(292) Framed-MTU = 1400
(292) User-Name = "huber@maier.de"
(292) State = 0xc1bb6d52c5bd74cd71f70b1b63d2de6d
(292) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(292) NAS-Port-Type = Wireless-802.11
(292) Acct-Session-Id = "8210066c"
(292) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(292) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(292) EAP-Message = 0x02060090198000000086160301004610000042410430e6273200b886f6ec078425238bddb09e5a05f24d5263d64286d15149e61f564a200a05561851b376c88b25289660ea8059f875b9fcdd648d759de86a49d00f140301000101160301003008112980457c2cafde104639f365e45fe165092deeb415
(292) Message-Authenticator = 0x4a20c696e15944ab24dbb23d375a237a
(292) NAS-Identifier = "CAPsMAN"
(292) NAS-IP-Address = 198.51.100.33
(292) Proxy-State = 0x323435
(292) session-state: No cached attributes
(292) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(292) authorize {
(292) policy filter_username {
(292) if (&User-Name) {
(292) if (&User-Name) -> TRUE
(292) if (&User-Name) {
(292) if (&User-Name =~ / /) {
(292) if (&User-Name =~ / /) -> FALSE
(292) if (&User-Name =~ /@[^@]*@/ ) {
(292) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(292) if (&User-Name =~ /\.\./ ) {
(292) if (&User-Name =~ /\.\./ ) -> FALSE
(292) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(292) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(292) if (&User-Name =~ /\.$/) {
(292) if (&User-Name =~ /\.$/) -> FALSE
(292) if (&User-Name =~ /@\./) {
(292) if (&User-Name =~ /@\./) -> FALSE
(292) } # if (&User-Name) = notfound
(292) } # policy filter_username = notfound
(292) [preprocess] = ok
(292) [chap] = noop
(292) [mschap] = noop
(292) [digest] = noop
(292) suffix: Checking for suffix after "@"
(292) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(292) suffix: No such realm "maier.de"
(292) [suffix] = noop
(292) eap: Peer sent EAP Response (code 2) ID 6 length 144
(292) eap: Continuing tunnel setup
(292) [eap] = ok
(292) } # authorize = ok
(292) Found Auth-Type = eap
(292) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(292) authenticate {
(292) eap: Expiring EAP session with state 0xc1bb6d52c5bd74cd
(292) eap: Finished EAP session with state 0xc1bb6d52c5bd74cd
(292) eap: Previous EAP request found for state 0xc1bb6d52c5bd74cd, released from the list
(292) eap: Peer sent packet with method EAP PEAP (25)
(292) eap: Calling submodule eap_peap to process data
(292) eap_peap: Continuing EAP-TLS
(292) eap_peap: Peer indicated complete TLS record size will be 134 bytes
(292) eap_peap: Got complete TLS record (134 bytes)
(292) eap_peap: [eaptls verify] = length included
(292) eap_peap: TLS_accept: SSLv3/TLS write server done
(292) eap_peap: <<< recv TLS 1.0 Handshake [length 0046], ClientKeyExchange
(292) eap_peap: TLS_accept: SSLv3/TLS read client key exchange
(292) eap_peap: TLS_accept: SSLv3/TLS read change cipher spec
(292) eap_peap: <<< recv TLS 1.0 Handshake [length 0010], Finished
(292) eap_peap: TLS_accept: SSLv3/TLS read finished
(292) eap_peap: >>> send TLS 1.0 ChangeCipherSpec [length 0001]
(292) eap_peap: TLS_accept: SSLv3/TLS write change cipher spec
(292) eap_peap: >>> send TLS 1.0 Handshake [length 0010], Finished
(292) eap_peap: TLS_accept: SSLv3/TLS write finished
(292) eap_peap: (other): SSL negotiation finished successfully
(292) eap_peap: SSL Connection Established
(292) eap_peap: [eaptls process] = handled
(292) eap: Sending EAP Request (code 1) ID 7 length 65
(292) eap: EAP session adding &reply:State = 0xc1bb6d52c4bc74cd
(292) [eap] = handled
(292) } # authenticate = handled
(292) Using Post-Auth-Type Challenge
(292) Post-Auth-Type sub-section not found. Ignoring.
(292) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(292) Sent Access-Challenge Id 127 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(292) EAP-Message = 0x0107004119001403010001011603010030ab13238f6949f5a033f0abfdf72c16d7ed93183a0b3fd0cde3f0aa7a2ccbc06920741721c65b97f6b6ae85c2389e4a29
(292) Message-Authenticator = 0x00000000000000000000000000000000
(292) State = 0xc1bb6d52c4bc74cd71f70b1b63d2de6d
(292) Proxy-State = 0x323435
(292) Finished request
Waking up in 4.3 seconds.
(293) Received Access-Request Id 206 from 198.51.100.34:1814 to 198.51.100.35:1812 length 208
(293) Service-Type = Framed-User
(293) Framed-MTU = 1400
(293) User-Name = "huber@maier.de"
(293) State = 0xc1bb6d52c4bc74cd71f70b1b63d2de6d
(293) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(293) NAS-Port-Type = Wireless-802.11
(293) Acct-Session-Id = "8210066c"
(293) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(293) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(293) EAP-Message = 0x020700061900
(293) Message-Authenticator = 0x4faa23bb37356e95a4b56db3510077e5
(293) NAS-Identifier = "CAPsMAN"
(293) NAS-IP-Address = 198.51.100.33
(293) Proxy-State = 0x323436
(293) session-state: No cached attributes
(293) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(293) authorize {
(293) policy filter_username {
(293) if (&User-Name) {
(293) if (&User-Name) -> TRUE
(293) if (&User-Name) {
(293) if (&User-Name =~ / /) {
(293) if (&User-Name =~ / /) -> FALSE
(293) if (&User-Name =~ /@[^@]*@/ ) {
(293) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(293) if (&User-Name =~ /\.\./ ) {
(293) if (&User-Name =~ /\.\./ ) -> FALSE
(293) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(293) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(293) if (&User-Name =~ /\.$/) {
(293) if (&User-Name =~ /\.$/) -> FALSE
(293) if (&User-Name =~ /@\./) {
(293) if (&User-Name =~ /@\./) -> FALSE
(293) } # if (&User-Name) = notfound
(293) } # policy filter_username = notfound
(293) [preprocess] = ok
(293) [chap] = noop
(293) [mschap] = noop
(293) [digest] = noop
(293) suffix: Checking for suffix after "@"
(293) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(293) suffix: No such realm "maier.de"
(293) [suffix] = noop
(293) eap: Peer sent EAP Response (code 2) ID 7 length 6
(293) eap: Continuing tunnel setup
(293) [eap] = ok
(293) } # authorize = ok
(293) Found Auth-Type = eap
(293) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(293) authenticate {
(293) eap: Expiring EAP session with state 0xc1bb6d52c4bc74cd
(293) eap: Finished EAP session with state 0xc1bb6d52c4bc74cd
(293) eap: Previous EAP request found for state 0xc1bb6d52c4bc74cd, released from the list
(293) eap: Peer sent packet with method EAP PEAP (25)
(293) eap: Calling submodule eap_peap to process data
(293) eap_peap: Continuing EAP-TLS
(293) eap_peap: Peer ACKed our handshake fragment. handshake is finished
(293) eap_peap: [eaptls verify] = success
(293) eap_peap: [eaptls process] = success
(293) eap_peap: Session established. Decoding tunneled attributes
(293) eap_peap: PEAP state TUNNEL ESTABLISHED
(293) eap: Sending EAP Request (code 1) ID 8 length 43
(293) eap: EAP session adding &reply:State = 0xc1bb6d52c7b374cd
(293) [eap] = handled
(293) } # authenticate = handled
(293) Using Post-Auth-Type Challenge
(293) Post-Auth-Type sub-section not found. Ignoring.
(293) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(293) Sent Access-Challenge Id 206 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(293) EAP-Message = 0x0108002b19001703010020de01b1062ff6496a0b2abd347516233c95eb1da09fbaa8ebee7480220fbeaea3
(293) Message-Authenticator = 0x00000000000000000000000000000000
(293) State = 0xc1bb6d52c7b374cd71f70b1b63d2de6d
(293) Proxy-State = 0x323436
(293) Finished request
Waking up in 4.1 seconds.
(292) Cleaning up request packet ID 127 with timestamp +647
(294) Received Access-Request Id 127 from 198.51.100.34:1814 to 198.51.100.35:1812 length 261
(294) Service-Type = Framed-User
(294) Framed-MTU = 1400
(294) User-Name = "huber@maier.de"
(294) State = 0xc1bb6d52c7b374cd71f70b1b63d2de6d
(294) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(294) NAS-Port-Type = Wireless-802.11
(294) Acct-Session-Id = "8210066c"
(294) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(294) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(294) EAP-Message = 0x0208003b190017030100300a794debdc99066c0fc331caeaf6999c8f089500097012607d9358bdfad6ee436988be48e83f2f3c6489f842595a7d18
(294) Message-Authenticator = 0x00edc01ad856c31f0aa9a603a4bf492f
(294) NAS-Identifier = "CAPsMAN"
(294) NAS-IP-Address = 198.51.100.33
(294) Proxy-State = 0x323437
(294) session-state: No cached attributes
(294) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(294) authorize {
(294) policy filter_username {
(294) if (&User-Name) {
(294) if (&User-Name) -> TRUE
(294) if (&User-Name) {
(294) if (&User-Name =~ / /) {
(294) if (&User-Name =~ / /) -> FALSE
(294) if (&User-Name =~ /@[^@]*@/ ) {
(294) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(294) if (&User-Name =~ /\.\./ ) {
(294) if (&User-Name =~ /\.\./ ) -> FALSE
(294) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(294) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(294) if (&User-Name =~ /\.$/) {
(294) if (&User-Name =~ /\.$/) -> FALSE
(294) if (&User-Name =~ /@\./) {
(294) if (&User-Name =~ /@\./) -> FALSE
(294) } # if (&User-Name) = notfound
(294) } # policy filter_username = notfound
(294) [preprocess] = ok
(294) [chap] = noop
(294) [mschap] = noop
(294) [digest] = noop
(294) suffix: Checking for suffix after "@"
(294) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(294) suffix: No such realm "maier.de"
(294) [suffix] = noop
(294) eap: Peer sent EAP Response (code 2) ID 8 length 59
(294) eap: Continuing tunnel setup
(294) [eap] = ok
(294) } # authorize = ok
(294) Found Auth-Type = eap
(294) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(294) authenticate {
(294) eap: Expiring EAP session with state 0xc1bb6d52c7b374cd
(294) eap: Finished EAP session with state 0xc1bb6d52c7b374cd
(294) eap: Previous EAP request found for state 0xc1bb6d52c7b374cd, released from the list
(294) eap: Peer sent packet with method EAP PEAP (25)
(294) eap: Calling submodule eap_peap to process data
(294) eap_peap: Continuing EAP-TLS
(294) eap_peap: [eaptls verify] = ok
(294) eap_peap: Done initial handshake
(294) eap_peap: [eaptls process] = ok
(294) eap_peap: Session established. Decoding tunneled attributes
(294) eap_peap: PEAP state WAITING FOR INNER IDENTITY
(294) eap_peap: Identity - huber@maier.de
(294) eap_peap: Got inner identity 'huber@maier.de'
(294) eap_peap: Setting default EAP type for tunneled EAP session
(294) eap_peap: Got tunneled request
(294) eap_peap: EAP-Message = 0x02080013016875626572406d616965722e6465
(294) eap_peap: Setting User-Name to huber@maier.de
(294) eap_peap: Sending tunneled request to inner-tunnel
(294) eap_peap: EAP-Message = 0x02080013016875626572406d616965722e6465
(294) eap_peap: FreeRADIUS-Proxied-To = 127.0.0.1
(294) eap_peap: User-Name = "huber@maier.de"
(294) Virtual server inner-tunnel received request
(294) EAP-Message = 0x02080013016875626572406d616965722e6465
(294) FreeRADIUS-Proxied-To = 127.0.0.1
(294) User-Name = "huber@maier.de"
(294) WARNING: Outer and inner identities are the same. User privacy is compromised.
(294) server inner-tunnel {
(294) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(294) authorize {
(294) policy filter_username {
(294) if (&User-Name) {
(294) if (&User-Name) -> TRUE
(294) if (&User-Name) {
(294) if (&User-Name =~ / /) {
(294) if (&User-Name =~ / /) -> FALSE
(294) if (&User-Name =~ /@[^@]*@/ ) {
(294) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(294) if (&User-Name =~ /\.\./ ) {
(294) if (&User-Name =~ /\.\./ ) -> FALSE
(294) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(294) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(294) if (&User-Name =~ /\.$/) {
(294) if (&User-Name =~ /\.$/) -> FALSE
(294) if (&User-Name =~ /@\./) {
(294) if (&User-Name =~ /@\./) -> FALSE
(294) } # if (&User-Name) = notfound
(294) } # policy filter_username = notfound
(294) [chap] = noop
(294) [mschap] = noop
(294) suffix: Checking for suffix after "@"
(294) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(294) suffix: No such realm "maier.de"
(294) [suffix] = noop
(294) update control {
(294) &Proxy-To-Realm := LOCAL
(294) } # update control = noop
(294) eap: Peer sent EAP Response (code 2) ID 8 length 19
(294) eap: EAP-Identity reply, returning 'ok' so we can short-circuit the rest of authorize
(294) [eap] = ok
(294) } # authorize = ok
(294) Found Auth-Type = eap
(294) # Executing group from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(294) authenticate {
(294) eap: Peer sent packet with method EAP Identity (1)
(294) eap: Calling submodule eap_mschapv2 to process data
(294) eap_mschapv2: Issuing Challenge
(294) eap: Sending EAP Request (code 1) ID 9 length 43
(294) eap: EAP session adding &reply:State = 0xdfebe385dfe2f9cb
(294) [eap] = handled
(294) } # authenticate = handled
(294) } # server inner-tunnel
(294) Virtual server sending reply
(294) EAP-Message = 0x0109002b1a01090026107d565e8e034bbd59952a4be50cada1bb667265657261646975732d332e302e3132
(294) Message-Authenticator = 0x00000000000000000000000000000000
(294) State = 0xdfebe385dfe2f9cb7f14999fa817c850
(294) eap_peap: Got tunneled reply code 11
(294) eap_peap: EAP-Message = 0x0109002b1a01090026107d565e8e034bbd59952a4be50cada1bb667265657261646975732d332e302e3132
(294) eap_peap: Message-Authenticator = 0x00000000000000000000000000000000
(294) eap_peap: State = 0xdfebe385dfe2f9cb7f14999fa817c850
(294) eap_peap: Got tunneled reply RADIUS code 11
(294) eap_peap: EAP-Message = 0x0109002b1a01090026107d565e8e034bbd59952a4be50cada1bb667265657261646975732d332e302e3132
(294) eap_peap: Message-Authenticator = 0x00000000000000000000000000000000
(294) eap_peap: State = 0xdfebe385dfe2f9cb7f14999fa817c850
(294) eap_peap: Got tunneled Access-Challenge
(294) eap: Sending EAP Request (code 1) ID 9 length 75
(294) eap: EAP session adding &reply:State = 0xc1bb6d52c6b274cd
(294) [eap] = handled
(294) } # authenticate = handled
(294) Using Post-Auth-Type Challenge
(294) Post-Auth-Type sub-section not found. Ignoring.
(294) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(294) Sent Access-Challenge Id 127 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(294) EAP-Message = 0x0109004b19001703010040b821a243d000f9af78e277fafe6614826076c423043af72fdee82dc61f23ffcefb4cc297faa1c045adad54f58e0b0244221158db8408ce7c0d1f5f22ea0b977c
(294) Message-Authenticator = 0x00000000000000000000000000000000
(294) State = 0xc1bb6d52c6b274cd71f70b1b63d2de6d
(294) Proxy-State = 0x323437
(294) Finished request
Waking up in 4.0 seconds.
(295) Received Access-Request Id 139 from 198.51.100.34:1814 to 198.51.100.35:1812 length 309
(295) Service-Type = Framed-User
(295) Framed-MTU = 1400
(295) User-Name = "huber@maier.de"
(295) State = 0xc1bb6d52c6b274cd71f70b1b63d2de6d
(295) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(295) NAS-Port-Type = Wireless-802.11
(295) Acct-Session-Id = "8210066c"
(295) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(295) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(295) EAP-Message = 0x0209006b190017030100606ae42580bb106d1207ea2ca18b4a47de3dda25a8b47f2623031a820569ac6b81843839da0b4d39df58f34818e59ac92969c2845b2930c047f9449df5fda29433423bad09b2dda17e5bbc88aad62fd6c42de59264aac0985d527e6568936d3895
(295) Message-Authenticator = 0xcd9252c36820fdc05fde92956d5d7bd8
(295) NAS-Identifier = "CAPsMAN"
(295) NAS-IP-Address = 198.51.100.33
(295) Proxy-State = 0x323438
(295) session-state: No cached attributes
(295) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(295) authorize {
(295) policy filter_username {
(295) if (&User-Name) {
(295) if (&User-Name) -> TRUE
(295) if (&User-Name) {
(295) if (&User-Name =~ / /) {
(295) if (&User-Name =~ / /) -> FALSE
(295) if (&User-Name =~ /@[^@]*@/ ) {
(295) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(295) if (&User-Name =~ /\.\./ ) {
(295) if (&User-Name =~ /\.\./ ) -> FALSE
(295) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(295) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(295) if (&User-Name =~ /\.$/) {
(295) if (&User-Name =~ /\.$/) -> FALSE
(295) if (&User-Name =~ /@\./) {
(295) if (&User-Name =~ /@\./) -> FALSE
(295) } # if (&User-Name) = notfound
(295) } # policy filter_username = notfound
(295) [preprocess] = ok
(295) [chap] = noop
(295) [mschap] = noop
(295) [digest] = noop
(295) suffix: Checking for suffix after "@"
(295) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(295) suffix: No such realm "maier.de"
(295) [suffix] = noop
(295) eap: Peer sent EAP Response (code 2) ID 9 length 107
(295) eap: Continuing tunnel setup
(295) [eap] = ok
(295) } # authorize = ok
(295) Found Auth-Type = eap
(295) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(295) authenticate {
(295) eap: Expiring EAP session with state 0xdfebe385dfe2f9cb
(295) eap: Finished EAP session with state 0xc1bb6d52c6b274cd
(295) eap: Previous EAP request found for state 0xc1bb6d52c6b274cd, released from the list
(295) eap: Peer sent packet with method EAP PEAP (25)
(295) eap: Calling submodule eap_peap to process data
(295) eap_peap: Continuing EAP-TLS
(295) eap_peap: [eaptls verify] = ok
(295) eap_peap: Done initial handshake
(295) eap_peap: [eaptls process] = ok
(295) eap_peap: Session established. Decoding tunneled attributes
(295) eap_peap: PEAP state phase2
(295) eap_peap: EAP method MSCHAPv2 (26)
(295) eap_peap: Got tunneled request
(295) eap_peap: EAP-Message = 0x020900491a02090044314315e3109c1d299eeb2cb26ea554ef8a00000000000000006a481b57c4b44aa87900dee5fd6edd6278e861f0c69b6ddb006875626572406d616965722e6465
(295) eap_peap: Setting User-Name to huber@maier.de
(295) eap_peap: Sending tunneled request to inner-tunnel
(295) eap_peap: EAP-Message = 0x020900491a02090044314315e3109c1d299eeb2cb26ea554ef8a00000000000000006a481b57c4b44aa87900dee5fd6edd6278e861f0c69b6ddb006875626572406d616965722e6465
(295) eap_peap: FreeRADIUS-Proxied-To = 127.0.0.1
(295) eap_peap: User-Name = "huber@maier.de"
(295) eap_peap: State = 0xdfebe385dfe2f9cb7f14999fa817c850
(295) Virtual server inner-tunnel received request
(295) EAP-Message = 0x020900491a02090044314315e3109c1d299eeb2cb26ea554ef8a00000000000000006a481b57c4b44aa87900dee5fd6edd6278e861f0c69b6ddb006875626572406d616965722e6465
(295) FreeRADIUS-Proxied-To = 127.0.0.1
(295) User-Name = "huber@maier.de"
(295) State = 0xdfebe385dfe2f9cb7f14999fa817c850
(295) WARNING: Outer and inner identities are the same. User privacy is compromised.
(295) server inner-tunnel {
(295) session-state: No cached attributes
(295) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(295) authorize {
(295) policy filter_username {
(295) if (&User-Name) {
(295) if (&User-Name) -> TRUE
(295) if (&User-Name) {
(295) if (&User-Name =~ / /) {
(295) if (&User-Name =~ / /) -> FALSE
(295) if (&User-Name =~ /@[^@]*@/ ) {
(295) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(295) if (&User-Name =~ /\.\./ ) {
(295) if (&User-Name =~ /\.\./ ) -> FALSE
(295) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(295) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(295) if (&User-Name =~ /\.$/) {
(295) if (&User-Name =~ /\.$/) -> FALSE
(295) if (&User-Name =~ /@\./) {
(295) if (&User-Name =~ /@\./) -> FALSE
(295) } # if (&User-Name) = notfound
(295) } # policy filter_username = notfound
(295) [chap] = noop
(295) [mschap] = noop
(295) suffix: Checking for suffix after "@"
(295) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(295) suffix: No such realm "maier.de"
(295) [suffix] = noop
(295) update control {
(295) &Proxy-To-Realm := LOCAL
(295) } # update control = noop
(295) eap: Peer sent EAP Response (code 2) ID 9 length 73
(295) eap: No EAP Start, assuming it's an on-going EAP conversation
(295) [eap] = updated
(295) [files] = noop
(295) sql: EXPAND %{User-Name}
(295) sql: --> huber@maier.de
(295) sql: SQL-User-Name set to 'huber@maier.de'
rlm_sql (sql): Closing connection (12): Hit idle_timeout, was idle for 225 seconds
rlm_sql (sql): You probably need to lower "min"
rlm_sql_mysql: Socket destructor called, closing socket
rlm_sql (sql): Closing connection (11): Hit idle_timeout, was idle for 225 seconds
rlm_sql (sql): You probably need to lower "min"
rlm_sql_mysql: Socket destructor called, closing socket
rlm_sql (sql): Closing connection (10): Hit idle_timeout, was idle for 225 seconds
rlm_sql (sql): You probably need to lower "min"
rlm_sql_mysql: Socket destructor called, closing socket
rlm_sql (sql): 0 of 0 connections in use. You may need to increase "spare"
rlm_sql (sql): Opening additional connection (13), 1 of 32 pending slots used
rlm_sql_mysql: Starting connect to MySQL server
rlm_sql_mysql: Connected to database 'WIRELESS-DB' on 198.51.100.34 via TCP/IP, server version 5.5.54-0+deb8u1, protocol version 10
rlm_sql (sql): Reserved connection (13)
(295) sql: EXPAND SELECT id, username, attribute, value, op FROM radcheck WHERE username = '%{SQL-User-Name}' ORDER BY id
(295) sql: --> SELECT id, username, attribute, value, op FROM radcheck WHERE username = 'huber@maier.de' ORDER BY id
(295) sql: Executing select query: SELECT id, username, attribute, value, op FROM radcheck WHERE username = 'huber@maier.de' ORDER BY id
(295) sql: User found in radcheck table
(295) sql: Conditional check items matched, merging assignment check items
(295) sql: Cleartext-Password := "test123"
(295) sql: EXPAND SELECT id, username, attribute, value, op FROM radreply WHERE username = '%{SQL-User-Name}' ORDER BY id
(295) sql: --> SELECT id, username, attribute, value, op FROM radreply WHERE username = 'huber@maier.de' ORDER BY id
(295) sql: Executing select query: SELECT id, username, attribute, value, op FROM radreply WHERE username = 'huber@maier.de' ORDER BY id
(295) sql: EXPAND SELECT groupname FROM radusergroup WHERE username = '%{SQL-User-Name}' ORDER BY priority
(295) sql: --> SELECT groupname FROM radusergroup WHERE username = 'huber@maier.de' ORDER BY priority
(295) sql: Executing select query: SELECT groupname FROM radusergroup WHERE username = 'huber@maier.de' ORDER BY priority
(295) sql: User found in the group table
(295) sql: EXPAND SELECT id, groupname, attribute, Value, op FROM radgroupcheck WHERE groupname = '%{SQL-Group}' ORDER BY id
(295) sql: --> SELECT id, groupname, attribute, Value, op FROM radgroupcheck WHERE groupname = 'filter' ORDER BY id
(295) sql: Executing select query: SELECT id, groupname, attribute, Value, op FROM radgroupcheck WHERE groupname = 'filter' ORDER BY id
(295) sql: Group "filter": Conditional check items matched
(295) sql: Group "filter": Merging assignment check items
(295) sql: EXPAND SELECT id, groupname, attribute, value, op FROM radgroupreply WHERE groupname = '%{SQL-Group}' ORDER BY id
(295) sql: --> SELECT id, groupname, attribute, value, op FROM radgroupreply WHERE groupname = 'filter' ORDER BY id
(295) sql: Executing select query: SELECT id, groupname, attribute, value, op FROM radgroupreply WHERE groupname = 'filter' ORDER BY id
(295) sql: Group "filter": Merging reply items
(295) sql: Mikrotik_Wireless_VLANID := 20
(295) sql: Mikrotik_Wireless_VLANIDtype := 0
rlm_sql (sql): Released connection (13)
rlm_sql (sql): Need 2 more connections to reach 10 spares
rlm_sql (sql): Opening additional connection (14), 1 of 31 pending slots used
rlm_sql_mysql: Starting connect to MySQL server
rlm_sql_mysql: Connected to database 'WIRELESS-DB' on 198.51.100.34 via TCP/IP, server version 5.5.54-0+deb8u1, protocol version 10
(295) [sql] = ok
(295) [expiration] = noop
(295) [logintime] = noop
(295) pap: WARNING: Auth-Type already set. Not setting to PAP
(295) [pap] = noop
(295) } # authorize = updated
(295) Found Auth-Type = eap
(295) # Executing group from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(295) authenticate {
(295) eap: Expiring EAP session with state 0xdfebe385dfe2f9cb
(295) eap: Finished EAP session with state 0xdfebe385dfe2f9cb
(295) eap: Previous EAP request found for state 0xdfebe385dfe2f9cb, released from the list
(295) eap: Peer sent packet with method EAP MSCHAPv2 (26)
(295) eap: Calling submodule eap_mschapv2 to process data
(295) eap_mschapv2: # Executing group from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(295) eap_mschapv2: authenticate {
(295) mschap: Found Cleartext-Password, hashing to create NT-Password
(295) mschap: Found Cleartext-Password, hashing to create LM-Password
(295) mschap: Creating challenge hash with username: huber@maier.de
(295) mschap: Client is using MS-CHAPv2
(295) mschap: Adding MS-CHAPv2 MPPE keys
(295) [mschap] = ok
(295) } # authenticate = ok
(295) MSCHAP Success
(295) eap: Sending EAP Request (code 1) ID 10 length 51
(295) eap: EAP session adding &reply:State = 0xdfebe385dee1f9cb
(295) [eap] = handled
(295) } # authenticate = handled
(295) } # server inner-tunnel
(295) Virtual server sending reply
(295) Mikrotik_Wireless_VLANID = 20
(295) Mikrotik_Wireless_VLANIDtype = 0
(295) EAP-Message = 0x010a00331a0309002e533d46343132363939343733433832373135323241414339393243303845363835304239463230463138
(295) Message-Authenticator = 0x00000000000000000000000000000000
(295) State = 0xdfebe385dee1f9cb7f14999fa817c850
(295) eap_peap: Got tunneled reply code 11
(295) eap_peap: Mikrotik_Wireless_VLANID = 20
(295) eap_peap: Mikrotik_Wireless_VLANIDtype = 0
(295) eap_peap: EAP-Message = 0x010a00331a0309002e533d46343132363939343733433832373135323241414339393243303845363835304239463230463138
(295) eap_peap: Message-Authenticator = 0x00000000000000000000000000000000
(295) eap_peap: State = 0xdfebe385dee1f9cb7f14999fa817c850
(295) eap_peap: Got tunneled reply RADIUS code 11
(295) eap_peap: Mikrotik_Wireless_VLANID = 20
(295) eap_peap: Mikrotik_Wireless_VLANIDtype = 0
(295) eap_peap: EAP-Message = 0x010a00331a0309002e533d46343132363939343733433832373135323241414339393243303845363835304239463230463138
(295) eap_peap: Message-Authenticator = 0x00000000000000000000000000000000
(295) eap_peap: State = 0xdfebe385dee1f9cb7f14999fa817c850
(295) eap_peap: Got tunneled Access-Challenge
(295) eap: Sending EAP Request (code 1) ID 10 length 91
(295) eap: EAP session adding &reply:State = 0xc1bb6d52c9b174cd
(295) [eap] = handled
(295) } # authenticate = handled
(295) Using Post-Auth-Type Challenge
(295) Post-Auth-Type sub-section not found. Ignoring.
(295) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(295) Sent Access-Challenge Id 139 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(295) EAP-Message = 0x010a005b1900170301005041bd8fac563a205f6c6c3511a79107e75a4b55fca1ffda4420bd15d26abcc1d1b44a207667c1c3674e9b6e0a678b9016a55701f40f4581278312e0365400e56f46593eb609fe69694300d5728bf0ad9b
(295) Message-Authenticator = 0x00000000000000000000000000000000
(295) State = 0xc1bb6d52c9b174cd71f70b1b63d2de6d
(295) Proxy-State = 0x323438
(295) Finished request
Waking up in 3.8 seconds.
(296) Received Access-Request Id 24 from 198.51.100.34:1814 to 198.51.100.35:1812 length 245
(296) Service-Type = Framed-User
(296) Framed-MTU = 1400
(296) User-Name = "huber@maier.de"
(296) State = 0xc1bb6d52c9b174cd71f70b1b63d2de6d
(296) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(296) NAS-Port-Type = Wireless-802.11
(296) Acct-Session-Id = "8210066c"
(296) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(296) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(296) EAP-Message = 0x020a002b19001703010020b020e7d4045a294752e394084ae591e79404fa60cbfed40fe1070d2a88dec862
(296) Message-Authenticator = 0x017e093c706b654367ef9536c3fce23a
(296) NAS-Identifier = "CAPsMAN"
(296) NAS-IP-Address = 198.51.100.33
(296) Proxy-State = 0x323439
(296) session-state: No cached attributes
(296) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(296) authorize {
(296) policy filter_username {
(296) if (&User-Name) {
(296) if (&User-Name) -> TRUE
(296) if (&User-Name) {
(296) if (&User-Name =~ / /) {
(296) if (&User-Name =~ / /) -> FALSE
(296) if (&User-Name =~ /@[^@]*@/ ) {
(296) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(296) if (&User-Name =~ /\.\./ ) {
(296) if (&User-Name =~ /\.\./ ) -> FALSE
(296) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(296) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(296) if (&User-Name =~ /\.$/) {
(296) if (&User-Name =~ /\.$/) -> FALSE
(296) if (&User-Name =~ /@\./) {
(296) if (&User-Name =~ /@\./) -> FALSE
(296) } # if (&User-Name) = notfound
(296) } # policy filter_username = notfound
(296) [preprocess] = ok
(296) [chap] = noop
(296) [mschap] = noop
(296) [digest] = noop
(296) suffix: Checking for suffix after "@"
(296) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(296) suffix: No such realm "maier.de"
(296) [suffix] = noop
(296) eap: Peer sent EAP Response (code 2) ID 10 length 43
(296) eap: Continuing tunnel setup
(296) [eap] = ok
(296) } # authorize = ok
(296) Found Auth-Type = eap
(296) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(296) authenticate {
(296) eap: Expiring EAP session with state 0xdfebe385dee1f9cb
(296) eap: Finished EAP session with state 0xc1bb6d52c9b174cd
(296) eap: Previous EAP request found for state 0xc1bb6d52c9b174cd, released from the list
(296) eap: Peer sent packet with method EAP PEAP (25)
(296) eap: Calling submodule eap_peap to process data
(296) eap_peap: Continuing EAP-TLS
(296) eap_peap: [eaptls verify] = ok
(296) eap_peap: Done initial handshake
(296) eap_peap: [eaptls process] = ok
(296) eap_peap: Session established. Decoding tunneled attributes
(296) eap_peap: PEAP state phase2
(296) eap_peap: EAP method MSCHAPv2 (26)
(296) eap_peap: Got tunneled request
(296) eap_peap: EAP-Message = 0x020a00061a03
(296) eap_peap: Setting User-Name to huber@maier.de
(296) eap_peap: Sending tunneled request to inner-tunnel
(296) eap_peap: EAP-Message = 0x020a00061a03
(296) eap_peap: FreeRADIUS-Proxied-To = 127.0.0.1
(296) eap_peap: User-Name = "huber@maier.de"
(296) eap_peap: State = 0xdfebe385dee1f9cb7f14999fa817c850
(296) Virtual server inner-tunnel received request
(296) EAP-Message = 0x020a00061a03
(296) FreeRADIUS-Proxied-To = 127.0.0.1
(296) User-Name = "huber@maier.de"
(296) State = 0xdfebe385dee1f9cb7f14999fa817c850
(296) WARNING: Outer and inner identities are the same. User privacy is compromised.
(296) server inner-tunnel {
(296) session-state: No cached attributes
(296) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(296) authorize {
(296) policy filter_username {
(296) if (&User-Name) {
(296) if (&User-Name) -> TRUE
(296) if (&User-Name) {
(296) if (&User-Name =~ / /) {
(296) if (&User-Name =~ / /) -> FALSE
(296) if (&User-Name =~ /@[^@]*@/ ) {
(296) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(296) if (&User-Name =~ /\.\./ ) {
(296) if (&User-Name =~ /\.\./ ) -> FALSE
(296) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(296) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(296) if (&User-Name =~ /\.$/) {
(296) if (&User-Name =~ /\.$/) -> FALSE
(296) if (&User-Name =~ /@\./) {
(296) if (&User-Name =~ /@\./) -> FALSE
(296) } # if (&User-Name) = notfound
(296) } # policy filter_username = notfound
(296) [chap] = noop
(296) [mschap] = noop
(296) suffix: Checking for suffix after "@"
(296) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(296) suffix: No such realm "maier.de"
(296) [suffix] = noop
(296) update control {
(296) &Proxy-To-Realm := LOCAL
(296) } # update control = noop
(296) eap: Peer sent EAP Response (code 2) ID 10 length 6
(296) eap: No EAP Start, assuming it's an on-going EAP conversation
(296) [eap] = updated
(296) [files] = noop
(296) sql: EXPAND %{User-Name}
(296) sql: --> huber@maier.de
(296) sql: SQL-User-Name set to 'huber@maier.de'
rlm_sql (sql): Reserved connection (13)
(296) sql: EXPAND SELECT id, username, attribute, value, op FROM radcheck WHERE username = '%{SQL-User-Name}' ORDER BY id
(296) sql: --> SELECT id, username, attribute, value, op FROM radcheck WHERE username = 'huber@maier.de' ORDER BY id
(296) sql: Executing select query: SELECT id, username, attribute, value, op FROM radcheck WHERE username = 'huber@maier.de' ORDER BY id
(296) sql: User found in radcheck table
(296) sql: Conditional check items matched, merging assignment check items
(296) sql: Cleartext-Password := "test123"
(296) sql: EXPAND SELECT id, username, attribute, value, op FROM radreply WHERE username = '%{SQL-User-Name}' ORDER BY id
(296) sql: --> SELECT id, username, attribute, value, op FROM radreply WHERE username = 'huber@maier.de' ORDER BY id
(296) sql: Executing select query: SELECT id, username, attribute, value, op FROM radreply WHERE username = 'huber@maier.de' ORDER BY id
(296) sql: EXPAND SELECT groupname FROM radusergroup WHERE username = '%{SQL-User-Name}' ORDER BY priority
(296) sql: --> SELECT groupname FROM radusergroup WHERE username = 'huber@maier.de' ORDER BY priority
(296) sql: Executing select query: SELECT groupname FROM radusergroup WHERE username = 'huber@maier.de' ORDER BY priority
(296) sql: User found in the group table
(296) sql: EXPAND SELECT id, groupname, attribute, Value, op FROM radgroupcheck WHERE groupname = '%{SQL-Group}' ORDER BY id
(296) sql: --> SELECT id, groupname, attribute, Value, op FROM radgroupcheck WHERE groupname = 'filter' ORDER BY id
(296) sql: Executing select query: SELECT id, groupname, attribute, Value, op FROM radgroupcheck WHERE groupname = 'filter' ORDER BY id
(296) sql: Group "filter": Conditional check items matched
(296) sql: Group "filter": Merging assignment check items
(296) sql: EXPAND SELECT id, groupname, attribute, value, op FROM radgroupreply WHERE groupname = '%{SQL-Group}' ORDER BY id
(296) sql: --> SELECT id, groupname, attribute, value, op FROM radgroupreply WHERE groupname = 'filter' ORDER BY id
(296) sql: Executing select query: SELECT id, groupname, attribute, value, op FROM radgroupreply WHERE groupname = 'filter' ORDER BY id
(296) sql: Group "filter": Merging reply items
(296) sql: Mikrotik_Wireless_VLANID := 20
(296) sql: Mikrotik_Wireless_VLANIDtype := 0
rlm_sql (sql): Released connection (13)
rlm_sql (sql): Need 1 more connections to reach 10 spares
rlm_sql (sql): Opening additional connection (15), 1 of 30 pending slots used
rlm_sql_mysql: Starting connect to MySQL server
rlm_sql_mysql: Connected to database 'WIRELESS-DB' on 198.51.100.34 via TCP/IP, server version 5.5.54-0+deb8u1, protocol version 10
(296) [sql] = ok
(296) [expiration] = noop
(296) [logintime] = noop
(296) pap: WARNING: Auth-Type already set. Not setting to PAP
(296) [pap] = noop
(296) } # authorize = updated
(296) Found Auth-Type = eap
(296) # Executing group from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(296) authenticate {
(296) eap: Expiring EAP session with state 0xdfebe385dee1f9cb
(296) eap: Finished EAP session with state 0xdfebe385dee1f9cb
(296) eap: Previous EAP request found for state 0xdfebe385dee1f9cb, released from the list
(296) eap: Peer sent packet with method EAP MSCHAPv2 (26)
(296) eap: Calling submodule eap_mschapv2 to process data
(296) eap: Sending EAP Success (code 3) ID 10 length 4
(296) eap: Freeing handler
(296) [eap] = ok
(296) } # authenticate = ok
(296) # Executing section post-auth from file /etc/freeradius/3.0/sites-enabled/inner-tunnel
(296) post-auth {
(296) sql: EXPAND .query
(296) sql: --> .query
(296) sql: Using query template 'query'
rlm_sql (sql): Reserved connection (14)
(296) sql: EXPAND %{User-Name}
(296) sql: --> huber@maier.de
(296) sql: SQL-User-Name set to 'huber@maier.de'
(296) sql: EXPAND INSERT INTO radpostauth (username, pass, reply, authdate) VALUES ( '%{SQL-User-Name}', '%{%{User-Password}:-%{Chap-Password}}', '%{reply:Packet-Type}', '%S')
(296) sql: --> INSERT INTO radpostauth (username, pass, reply, authdate) VALUES ( 'huber@maier.de', '', 'Access-Accept', '2017-03-12 02:43:33')
(296) sql: Executing query: INSERT INTO radpostauth (username, pass, reply, authdate) VALUES ( 'huber@maier.de', '', 'Access-Accept', '2017-03-12 02:43:33')
(296) sql: SQL query returned: success
(296) sql: 1 record(s) updated
rlm_sql (sql): Released connection (14)
(296) [sql] = ok
(296) } # post-auth = ok
(296) } # server inner-tunnel
(296) Virtual server sending reply
(296) Mikrotik_Wireless_VLANID = 20
(296) Mikrotik_Wireless_VLANIDtype = 0
(296) MS-MPPE-Encryption-Policy = Encryption-Required
(296) MS-MPPE-Encryption-Types = 4
(296) MS-MPPE-Send-Key = 0xb46dbc7a67f65c9c64e2822b272ae323
(296) MS-MPPE-Recv-Key = 0x22fdb78706b3671347326a57467ed1c8
(296) EAP-Message = 0x030a0004
(296) Message-Authenticator = 0x00000000000000000000000000000000
(296) User-Name = "huber@maier.de"
(296) eap_peap: Got tunneled reply code 2
(296) eap_peap: Mikrotik_Wireless_VLANID = 20
(296) eap_peap: Mikrotik_Wireless_VLANIDtype = 0
(296) eap_peap: MS-MPPE-Encryption-Policy = Encryption-Required
(296) eap_peap: MS-MPPE-Encryption-Types = 4
(296) eap_peap: MS-MPPE-Send-Key = 0xb46dbc7a67f65c9c64e2822b272ae323
(296) eap_peap: MS-MPPE-Recv-Key = 0x22fdb78706b3671347326a57467ed1c8
(296) eap_peap: EAP-Message = 0x030a0004
(296) eap_peap: Message-Authenticator = 0x00000000000000000000000000000000
(296) eap_peap: User-Name = "huber@maier.de"
(296) eap_peap: Got tunneled reply RADIUS code 2
(296) eap_peap: Mikrotik_Wireless_VLANID = 20
(296) eap_peap: Mikrotik_Wireless_VLANIDtype = 0
(296) eap_peap: MS-MPPE-Encryption-Policy = Encryption-Required
(296) eap_peap: MS-MPPE-Encryption-Types = 4
(296) eap_peap: MS-MPPE-Send-Key = 0xb46dbc7a67f65c9c64e2822b272ae323
(296) eap_peap: MS-MPPE-Recv-Key = 0x22fdb78706b3671347326a57467ed1c8
(296) eap_peap: EAP-Message = 0x030a0004
(296) eap_peap: Message-Authenticator = 0x00000000000000000000000000000000
(296) eap_peap: User-Name = "huber@maier.de"
(296) eap_peap: Tunneled authentication was successful
(296) eap_peap: SUCCESS
(296) eap: Sending EAP Request (code 1) ID 11 length 43
(296) eap: EAP session adding &reply:State = 0xc1bb6d52c8b074cd
(296) [eap] = handled
(296) } # authenticate = handled
(296) Using Post-Auth-Type Challenge
(296) Post-Auth-Type sub-section not found. Ignoring.
(296) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(296) Sent Access-Challenge Id 24 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(296) EAP-Message = 0x010b002b190017030100200b748b0dde6486bda29a6968c2b6be0da9452c69aed819e0999c6ba0296b38ec
(296) Message-Authenticator = 0x00000000000000000000000000000000
(296) State = 0xc1bb6d52c8b074cd71f70b1b63d2de6d
(296) Proxy-State = 0x323439
(296) Finished request
Waking up in 3.6 seconds.
(297) Received Access-Request Id 33 from 198.51.100.34:1814 to 198.51.100.35:1812 length 245
(297) Service-Type = Framed-User
(297) Framed-MTU = 1400
(297) User-Name = "huber@maier.de"
(297) State = 0xc1bb6d52c8b074cd71f70b1b63d2de6d
(297) NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
(297) NAS-Port-Type = Wireless-802.11
(297) Acct-Session-Id = "8210066c"
(297) Calling-Station-Id = "A0-88-B4-D7-58-A4"
(297) Called-Station-Id = "6e-3b-6b-76-95-e9:WIRELESS"
(297) EAP-Message = 0x020b002b19001703010020ac6a7c9674b779295b536433c77b125c40b8b554b41e3fd187c8080acb970712
(297) Message-Authenticator = 0x21e49cf582314e954828d6b4ccde1255
(297) NAS-Identifier = "CAPsMAN"
(297) NAS-IP-Address = 198.51.100.33
(297) Proxy-State = 0x323530
(297) session-state: No cached attributes
(297) # Executing section authorize from file /etc/freeradius/3.0/sites-enabled/default
(297) authorize {
(297) policy filter_username {
(297) if (&User-Name) {
(297) if (&User-Name) -> TRUE
(297) if (&User-Name) {
(297) if (&User-Name =~ / /) {
(297) if (&User-Name =~ / /) -> FALSE
(297) if (&User-Name =~ /@[^@]*@/ ) {
(297) if (&User-Name =~ /@[^@]*@/ ) -> FALSE
(297) if (&User-Name =~ /\.\./ ) {
(297) if (&User-Name =~ /\.\./ ) -> FALSE
(297) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) {
(297) if ((&User-Name =~ /@/) && (&User-Name !~ /@(.+)\.(.+)$/)) -> FALSE
(297) if (&User-Name =~ /\.$/) {
(297) if (&User-Name =~ /\.$/) -> FALSE
(297) if (&User-Name =~ /@\./) {
(297) if (&User-Name =~ /@\./) -> FALSE
(297) } # if (&User-Name) = notfound
(297) } # policy filter_username = notfound
(297) [preprocess] = ok
(297) [chap] = noop
(297) [mschap] = noop
(297) [digest] = noop
(297) suffix: Checking for suffix after "@"
(297) suffix: Looking up realm "maier.de" for User-Name = "huber@maier.de"
(297) suffix: No such realm "maier.de"
(297) [suffix] = noop
(297) eap: Peer sent EAP Response (code 2) ID 11 length 43
(297) eap: Continuing tunnel setup
(297) [eap] = ok
(297) } # authorize = ok
(297) Found Auth-Type = eap
(297) # Executing group from file /etc/freeradius/3.0/sites-enabled/default
(297) authenticate {
(297) eap: Expiring EAP session with state 0xc1bb6d52c8b074cd
(297) eap: Finished EAP session with state 0xc1bb6d52c8b074cd
(297) eap: Previous EAP request found for state 0xc1bb6d52c8b074cd, released from the list
(297) eap: Peer sent packet with method EAP PEAP (25)
(297) eap: Calling submodule eap_peap to process data
(297) eap_peap: Continuing EAP-TLS
(297) eap_peap: [eaptls verify] = ok
(297) eap_peap: Done initial handshake
(297) eap_peap: [eaptls process] = ok
(297) eap_peap: Session established. Decoding tunneled attributes
(297) eap_peap: PEAP state send tlv success
(297) eap_peap: Received EAP-TLV response
(297) eap_peap: Success
(297) eap_peap: No information to cache: session caching will be disabled for session 38af41516247bd0f9e27b3e091fcc6da1696efd86eb8944f7694a973b9f2afa8
(297) eap: Sending EAP Success (code 3) ID 11 length 4
(297) eap: Freeing handler
(297) [eap] = ok
(297) } # authenticate = ok
(297) # Executing section post-auth from file /etc/freeradius/3.0/sites-enabled/default
(297) post-auth {
(297) update {
(297) No attributes updated
(297) } # update = noop
(297) sql: EXPAND .query
(297) sql: --> .query
(297) sql: Using query template 'query'
rlm_sql (sql): Reserved connection (13)
(297) sql: EXPAND %{User-Name}
(297) sql: --> huber@maier.de
(297) sql: SQL-User-Name set to 'huber@maier.de'
(297) sql: EXPAND INSERT INTO radpostauth (username, pass, reply, authdate) VALUES ( '%{SQL-User-Name}', '%{%{User-Password}:-%{Chap-Password}}', '%{reply:Packet-Type}', '%S')
(297) sql: --> INSERT INTO radpostauth (username, pass, reply, authdate) VALUES ( 'huber@maier.de', '', 'Access-Accept', '2017-03-12 02:43:33')
(297) sql: Executing query: INSERT INTO radpostauth (username, pass, reply, authdate) VALUES ( 'huber@maier.de', '', 'Access-Accept', '2017-03-12 02:43:33')
(297) sql: SQL query returned: success
(297) sql: 1 record(s) updated
rlm_sql (sql): Released connection (13)
(297) [sql] = ok
(297) [exec] = noop
(297) policy remove_reply_message_if_eap {
(297) if (&reply:EAP-Message && &reply:Reply-Message) {
(297) if (&reply:EAP-Message && &reply:Reply-Message) -> FALSE
(297) else {
(297) [noop] = noop
(297) } # else = noop
(297) } # policy remove_reply_message_if_eap = noop
(297) } # post-auth = ok
(297) Sent Access-Accept Id 33 from 198.51.100.35:1812 to 198.51.100.34:1814 length 0
(297) MS-MPPE-Recv-Key = 0x4f29d1dc9930f329a1dd162b84f2be654b059679ba5d860dae483e0f08c2765d
(297) MS-MPPE-Send-Key = 0x6d0f47900588793cf17c1e80b1942a528363bf004d4e8cc4863bb3fbc68149b2
(297) EAP-Message = 0x030b0004
(297) Message-Authenticator = 0x00000000000000000000000000000000
(297) User-Name = "huber@maier.de"
(297) Proxy-State = 0x323530
(297) Finished request
Waking up in 3.5 seconds.
MT Log output
03:43:29 radius,debug,packet sending Access-Request with id 240 to 198.51.100.34:1812
03:43:29 radius,debug,packet Signature = 0xe34ebd531d25863a352a4b41b4536a63
03:43:29 radius,debug,packet Service-Type = 2
03:43:29 radius,debug,packet Framed-MTU = 1400
03:43:29 radius,debug,packet User-Name = "huber@maier.de"
03:43:29 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:29 radius,debug,packet NAS-Port-Type = 19
03:43:29 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:29 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:29 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:29 radius,debug,packet EAP-Message = 0x02010013016875626572406d61696572
03:43:29 radius,debug,packet 2e6465
03:43:29 radius,debug,packet Message-Authenticator = 0x814749b3dbc5024cdec13641cbf90759
03:43:29 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:29 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:29 radius,debug,packet received Access-Challenge with id 240 from 198.51.100.34:1812
03:43:29 radius,debug,packet Signature = 0xb993496a3b9b7a4fece3cd4b1ae08545
03:43:29 radius,debug,packet EAP-Message = 0x010200061920
03:43:29 radius,debug,packet Message-Authenticator = 0x6cb1ddfbede3df413c5ecfade2aadfa8
03:43:29 radius,debug,packet State = 0xc1bb6d52c1b974cd71f70b1b63d2de6d
03:43:29 radius,debug,packet sending Access-Request with id 241 to 198.51.100.34:1812
03:43:29 radius,debug,packet Signature = 0x0f863f4392dc12a38cb61e495c62a8b7
03:43:29 radius,debug,packet Service-Type = 2
03:43:29 radius,debug,packet Framed-MTU = 1400
03:43:29 radius,debug,packet User-Name = "huber@maier.de"
03:43:29 radius,debug,packet State = 0xc1bb6d52c1b974cd71f70b1b63d2de6d
03:43:29 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:29 radius,debug,packet NAS-Port-Type = 19
03:43:29 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:29 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:29 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:29 radius,debug,packet EAP-Message = 0x02020071198000000067160301006201
03:43:29 radius,debug,packet 00005e030158c4b5d9c5b21146e2f5a3
03:43:29 radius,debug,packet 7450b85f73a5d347667ddaf99d6fe35c
03:43:29 radius,debug,packet 88cb6bc0a200001cc014c01300390033
03:43:29 radius,debug,packet 0035002fc00ac00900380032000a0013
03:43:29 radius,debug,packet 0005000401000019000a000600040017
03:43:29 radius,debug,packet 0018000b0002010000170000ff010001
03:43:29 radius,debug,packet 00
03:43:29 radius,debug,packet Message-Authenticator = 0x5d0d2635ebe10c9f3d0e7d2a863d1fc0
03:43:29 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:29 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:29 radius,debug,packet received Access-Challenge with id 241 from 198.51.100.34:1812
03:43:29 radius,debug,packet Signature = 0x29e839b708538a82c26f2ff29f79c2e5
03:43:29 radius,debug,packet EAP-Message = 0x010303ec19c000000dc0160301005d02
03:43:29 radius,debug,packet 000059030105ce231e2ab32150a342f7
03:43:29 radius,debug,packet a6e9015024385fd97b68c2cc50838886
03:43:29 radius,debug,packet 78317d798f2038af41516247bd0f9e27
03:43:29 radius,debug,packet b3e091fcc6da1696efd86eb8944f7694
03:43:29 radius,debug,packet a973b9f2afa8c014000011ff01000100
03:43:29 radius,debug,packet 000b000403000102001700001603010c
03:43:29 radius,debug,packet 000b000bfc000bf900060a3082060630
03:43:29 radius,debug,packet 8204eea003020102021048e3fb41169a
03:43:29 radius,debug,packet f201c0e110080cf92468300d06092a86
03:43:29 radius,debug,packet 4886f70d01010b05003078310b300906
03:43:29 radius,debug,packet 035504061302494c3116301406035504
03:43:29 radius,debug,packet 0a130d5374617274436f6d204c74642e
03:43:29 radius,debug,packet 31293027060355040b13205374617274
03:43:29 radius,debug,packet 436f6d2043657274696669636174696f
03:43:29 radius,debug,packet 6e20417574686f726974793126
03:43:29 radius,debug,packet EAP-Message = 0x30240603550403131d5374617274436f
03:43:29 radius,debug,packet 6d20436c617373203120445620536572
03:43:29 radius,debug,packet 766572204341301e170d313630383135
03:43:29 radius,debug,packet 3039333233305a170d31373038313530
03:43:29 radius,debug,packet 39333233305a3033310b300906035504
03:43:29 radius,debug,packet 06130244453124302206035504030c1b
03:43:29 radius,debug,packet 7261646975732e706661727265692d72
03:43:29 radius,debug,packet 7564657274696e672e64653082012230
03:43:29 radius,debug,packet 0d06092a864886f70d01010105000382
03:43:29 radius,debug,packet 010f003082010a0282010100d8892724
03:43:29 radius,debug,packet 877a09f642af4a9729415279ad905c2b
03:43:29 radius,debug,packet 760a2bfcab2d69f363013a66a2d2d5ef
03:43:29 radius,debug,packet 6296ca3625c5487d470209e4676660bd
03:43:29 radius,debug,packet 5a2b3166e1de7899b694343ff47e20d7
03:43:29 radius,debug,packet c1f95d51c87aba08adb82a0052d650c1
03:43:29 radius,debug,packet 1f9dbae92cf3cc832d10da9f1c
03:43:29 radius,debug,packet EAP-Message = 0x707ef5c76a71c706ea2164479cc937c9
03:43:29 radius,debug,packet a8abfd11c8c5070ce714e31caeafceaf
03:43:29 radius,debug,packet 70469c9685bcbeacdfd66a0dfb04c251
03:43:29 radius,debug,packet 2b0c301803344ab7dd15c8ebb5175f58
03:43:29 radius,debug,packet 5592d4020a7996eb9d32e875a8bf5383
03:43:29 radius,debug,packet 1b3670bb56979e6066ab5f23ae6ab0e2
03:43:29 radius,debug,packet 542ac8c64db3227db9db4e9e5500b4d7
03:43:29 radius,debug,packet 9fd36da34c5021d35a4ed027fc0f7439
03:43:29 radius,debug,packet 47e457a1851b54f6c9994510df8983f4
03:43:29 radius,debug,packet a4eb1caa781f9877cd6718903560a902
03:43:29 radius,debug,packet 03010001a38202cf308202cb300e0603
03:43:29 radius,debug,packet 551d0f0101ff0404030205a0301d0603
03:43:29 radius,debug,packet 551d250416301406082b060105050703
03:43:29 radius,debug,packet 0206082b060105050703013009060355
03:43:29 radius,debug,packet 1d1304023000301d0603551d0e041604
03:43:29 radius,debug,packet 14de56c55516583d7e3c243664
03:43:29 radius,debug,packet EAP-Message = 0x38175586ad44f656301f0603551d2304
03:43:29 radius,debug,packet 1830168014d7914e01c4b0bff8c86793
03:43:29 radius,debug,packet 449ce733faad930caf306f06082b0601
03:43:29 radius,debug,packet 050507010104633061302406082b0601
03:43:29 radius,debug,packet 05050730018618687474703a2f2f6f63
03:43:29 radius,debug,packet 73702e737461727473736c2e636f6d30
03:43:29 radius,debug,packet 3906082b06010505073002862d687474
03:43:29 radius,debug,packet 703a2f2f6169612e737461727473736c
03:43:29 radius,debug,packet 2e636f6d2f63657274732f7363612e73
03:43:29 radius,debug,packet 6572766572312e63727430380603551d
03:43:29 radius,debug,packet 1f0431302f302da02ba0298627687474
03:43:29 radius,debug,packet 703a2f2f63726c2e737461727473736c
03:43:29 radius,debug,packet 2e636f6d2f7363612d73657276657231
03:43:29 radius,debug,packet 2e63726c30260603551d11041f301d82
03:43:29 radius,debug,packet 1b7261646975732e706661727265692d
03:43:29 radius,debug,packet 7275646572
03:43:29 radius,debug,packet Message-Authenticator = 0x2c75a9a3114432bb331544a554b47f2e
03:43:29 radius,debug,packet State = 0xc1bb6d52c0b874cd71f70b1b63d2de6d
03:43:29 radius,debug,packet sending Access-Request with id 242 to 198.51.100.34:1812
03:43:29 radius,debug,packet Signature = 0x0874fa5daee3b764dbe9deb54ca26aec
03:43:29 radius,debug,packet Service-Type = 2
03:43:29 radius,debug,packet Framed-MTU = 1400
03:43:29 radius,debug,packet User-Name = "huber@maier.de"
03:43:29 radius,debug,packet State = 0xc1bb6d52c0b874cd71f70b1b63d2de6d
03:43:29 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:29 radius,debug,packet NAS-Port-Type = 19
03:43:29 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:29 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:29 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:29 radius,debug,packet EAP-Message = 0x020300061900
03:43:29 radius,debug,packet Message-Authenticator = 0x8e8f81bc766ba509c1ed61d4d6b4bc6d
03:43:29 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:29 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:29 radius,debug,packet received Access-Challenge with id 242 from 198.51.100.34:1812
03:43:29 radius,debug,packet Signature = 0x9c904f22ff0e3bb45dae06fb522c784a
03:43:29 radius,debug,packet EAP-Message = 0x010403e8194074696e672e6465302306
03:43:29 radius,debug,packet 03551d12041c301a8618687474703a2f
03:43:29 radius,debug,packet 2f7777772e737461727473736c2e636f
03:43:29 radius,debug,packet 6d2f30510603551d20044a3048300806
03:43:29 radius,debug,packet 0667810c010201303c060b2b06010401
03:43:29 radius,debug,packet 81b537010205302d302b06082b060105
03:43:29 radius,debug,packet 05070201161f68747470733a2f2f7777
03:43:29 radius,debug,packet 772e737461727473736c2e636f6d2f70
03:43:29 radius,debug,packet 6f6c69637930820102060a2b06010401
03:43:29 radius,debug,packet d6790204020481f30481f000ee007500
03:43:29 radius,debug,packet 68f698f81f6482be3a8ceeb9281d4cfc
03:43:29 radius,debug,packet 71515d6793d444d10a67acbb4f4ffbc4
03:43:29 radius,debug,packet 000001568da8c1c60000040300463044
03:43:29 radius,debug,packet 02202ef52672e8f3f6b991b02ceeb3ef
03:43:29 radius,debug,packet 0091cbc3d3e7548462491cc83fce81c8
03:43:29 radius,debug,packet c10f022000c2ffa1239bc8ac1e
03:43:29 radius,debug,packet EAP-Message = 0x41eab74e0f446447e2a91790de6d2593
03:43:29 radius,debug,packet e2d34f9c51d63a007500a4b90990b418
03:43:29 radius,debug,packet 581487bb13a2cc67700a3c359804f91b
03:43:29 radius,debug,packet dfb8e377cd0ec80ddc10000001568da8
03:43:29 radius,debug,packet c1f10000040300463044022004005a1a
03:43:29 radius,debug,packet d2fa82dd5ba66bd32554ac73273544d7
03:43:29 radius,debug,packet a312e1b43d235cc53ad7cbc702200b80
03:43:29 radius,debug,packet 1d9f745db7433f684a6406467d03fc1f
03:43:29 radius,debug,packet 344299e160f2356e496e49e31118300d
03:43:29 radius,debug,packet 06092a864886f70d01010b0500038201
03:43:29 radius,debug,packet 0100ae35547982b43f25feed4412df12
03:43:29 radius,debug,packet 45a806e9dc36b19cf7d6ea255a784513
03:43:29 radius,debug,packet afb1cb8d757b1103a972a5ea3eb4d2a9
03:43:29 radius,debug,packet 9f47fbb50d6d8714dcc300519d985bc9
03:43:29 radius,debug,packet d9a74a16d057ad60ca45845ed23a8b8f
03:43:29 radius,debug,packet d374dd3da6893e8ed750fbaaf1
03:43:29 radius,debug,packet EAP-Message = 0x450efe1d0af3e4157861f62617f87dea
03:43:29 radius,debug,packet affb3d6ffd8a6105e1fee8134c7fcd5e
03:43:29 radius,debug,packet 81480d85cec880f6cd3fcae9cf079654
03:43:29 radius,debug,packet 13398b6c80ca3d286d61aaf6b12eadcb
03:43:29 radius,debug,packet c1c5d5ba5bcedb57801020a355548d2a
03:43:29 radius,debug,packet 55468c036785a94dc50f924ccf5d6e52
03:43:29 radius,debug,packet 6d2bb55ec75e940ea5a10c93890aca47
03:43:29 radius,debug,packet 7b1fb53185677eb497145cdd3b9135cb
03:43:29 radius,debug,packet 09acc070c06b984e35e512a8e6b006f9
03:43:29 radius,debug,packet b0974ac52fae9b47b4e891b062d43d04
03:43:29 radius,debug,packet 2cb5ef4cfe0005e9308205e5308203cd
03:43:29 radius,debug,packet a00302010202106a5dc3e53b4e4fd07b
03:43:29 radius,debug,packet 691ea5fcec646b300d06092a864886f7
03:43:29 radius,debug,packet 0d01010b0500307d310b300906035504
03:43:29 radius,debug,packet 061302494c31163014060355040a130d
03:43:29 radius,debug,packet 5374617274436f6d204c74642e
03:43:29 radius,debug,packet EAP-Message = 0x312b3029060355040b13225365637572
03:43:29 radius,debug,packet 65204469676974616c20436572746966
03:43:29 radius,debug,packet 6963617465205369676e696e67312930
03:43:29 radius,debug,packet 27060355040313205374617274436f6d
03:43:29 radius,debug,packet 2043657274696669636174696f6e2041
03:43:29 radius,debug,packet 7574686f72697479301e170d31353132
03:43:29 radius,debug,packet 31363031303030355a170d3330313231
03:43:29 radius,debug,packet 363031303030355a3078310b30090603
03:43:29 radius,debug,packet 5504061302494c31163014060355040a
03:43:29 radius,debug,packet 130d5374617274436f6d204c74642e31
03:43:29 radius,debug,packet 293027060355040b1320537461727443
03:43:29 radius,debug,packet 6f6d2043657274696669636174696f6e
03:43:29 radius,debug,packet 20417574686f72697479312630240603
03:43:29 radius,debug,packet 550403131d5374617274436f6d20436c
03:43:29 radius,debug,packet 61737320312044562053657276657220
03:43:29 radius,debug,packet 43
03:43:29 radius,debug,packet Message-Authenticator = 0xb1d0d6b43f1dc47614b396a52d8ae590
03:43:29 radius,debug,packet State = 0xc1bb6d52c3bf74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 243 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x1f03080861b4bd7a28f95e14a5323e11
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c3bf74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x020400061900
03:43:30 radius,debug,packet Message-Authenticator = 0x88ae4f898522d679df4e16314f42bdb8
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:30 radius,debug,packet received Access-Challenge with id 243 from 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x33db09ac15bb315d8e2b95624e417a04
03:43:30 radius,debug,packet EAP-Message = 0x010503e819404130820122300d06092a
03:43:30 radius,debug,packet 864886f70d01010105000382010f0030
03:43:30 radius,debug,packet 82010a0282010100daecf4aa88678bb0
03:43:30 radius,debug,packet 4b626696bfc94468e6c22b4ca033ceac
03:43:30 radius,debug,packet 79e376c3d156e075af41b40a4580efcb
03:43:30 radius,debug,packet 8de416e326143e111e41e7d4c93bb228
03:43:30 radius,debug,packet d7909fc5f0d1fee538db8a7b3bb45202
03:43:30 radius,debug,packet 65777e41ed8e0c231c59b38ba18079e2
03:43:30 radius,debug,packet c339d78b6c664ea6dcce25662de0993e
03:43:30 radius,debug,packet c848588d74aa5ffc2ddd6706ac59e6be
03:43:30 radius,debug,packet 75b2e9c1059911c33aa025e65bfe8bde
03:43:30 radius,debug,packet 4c100210b41a1266dab055ad8103bd9a
03:43:30 radius,debug,packet b510adc1bfe8398005bc0d57eeb146a2
03:43:30 radius,debug,packet a325b4c1f41d9cab4e2efd4ce2bb5ece
03:43:30 radius,debug,packet b2ad13c4f9b63c9e2af16a317f77f8b6
03:43:30 radius,debug,packet 15953f15b3eb03d76b379dc95d
03:43:30 radius,debug,packet EAP-Message = 0xa840cb53cf488818e0e85b1b2df33629
03:43:30 radius,debug,packet eb7fdd16dfbe081f40c3d0b218a9761a
03:43:30 radius,debug,packet d92fcab5d2389b4e5562190203010001
03:43:30 radius,debug,packet a382016430820160300e0603551d0f01
03:43:30 radius,debug,packet 01ff040403020106301d0603551d2504
03:43:30 radius,debug,packet 16301406082b0601050507030206082b
03:43:30 radius,debug,packet 0601050507030130120603551d130101
03:43:30 radius,debug,packet ff040830060101ff0201003032060355
03:43:30 radius,debug,packet 1d1f042b30293027a025a02386216874
03:43:30 radius,debug,packet 74703a2f2f63726c2e73746172747373
03:43:30 radius,debug,packet 6c2e636f6d2f73667363612e63726c30
03:43:30 radius,debug,packet 6606082b06010505070101045a305830
03:43:30 radius,debug,packet 2406082b060105050730018618687474
03:43:30 radius,debug,packet 703a2f2f6f6373702e73746172747373
03:43:30 radius,debug,packet 6c2e636f6d303006082b060105050730
03:43:30 radius,debug,packet 028624687474703a2f2f616961
03:43:30 radius,debug,packet EAP-Message = 0x2e737461727473736c2e636f6d2f6365
03:43:30 radius,debug,packet 7274732f63612e637274301d0603551d
03:43:30 radius,debug,packet 0e04160414d7914e01c4b0bff8c86793
03:43:30 radius,debug,packet 449ce733faad930caf301f0603551d23
03:43:30 radius,debug,packet 0418301680144e0bef1aa4405ba51769
03:43:30 radius,debug,packet 8730ca346843d041aef2303f0603551d
03:43:30 radius,debug,packet 200438303630340604551d2000302c30
03:43:30 radius,debug,packet 2a06082b06010505070201161e687474
03:43:30 radius,debug,packet 703a2f2f7777772e737461727473736c
03:43:30 radius,debug,packet 2e636f6d2f706f6c696379300d06092a
03:43:30 radius,debug,packet 864886f70d01010b050003820201008e
03:43:30 radius,debug,packet e73fbde44bba82883d2bd7bb0dab505d
03:43:30 radius,debug,packet f7942fccead58723d072a8dd9bc58518
03:43:30 radius,debug,packet d42c056b323ec9ad446d7e86738930e5
03:43:30 radius,debug,packet dfd82f30384bbe8379105118416cab7b
03:43:30 radius,debug,packet 9c92b05806799407202d338444
03:43:30 radius,debug,packet EAP-Message = 0xc82d2c8013b24229a109fff00f9e4710
03:43:30 radius,debug,packet 7f1e39f063ae26f8bea762694716bc49
03:43:30 radius,debug,packet cfc7549f47a80ebced06db2451599543
03:43:30 radius,debug,packet f922a2ed09bf3265505445de0d9bffb4
03:43:30 radius,debug,packet d435c1ce89a840fc002b771897d6ebe9
03:43:30 radius,debug,packet 0f9e2a608a3ca37a5f8213d60c2dc17b
03:43:30 radius,debug,packet 9c6b57f73a96536d414f74fcf52af3f5
03:43:30 radius,debug,packet a8216dfab36279298e04defa5daf5f7f
03:43:30 radius,debug,packet 3a01072cd5767be4d8e1eea29989abf7
03:43:30 radius,debug,packet 8717e137b3e185613e8ec63adecff944
03:43:30 radius,debug,packet 6c1be01261b25d93996a3e977839c1c4
03:43:30 radius,debug,packet e21844e0df9d91bdf5ccb6ab95ad0cb1
03:43:30 radius,debug,packet caba232880918ef3d3d6688da32b502a
03:43:30 radius,debug,packet e6c6b48f9e63a7625e1576d189e2b0e4
03:43:30 radius,debug,packet 22ab782222351f4ca5a7df89e2e06d37
03:43:30 radius,debug,packet 0a
03:43:30 radius,debug,packet Message-Authenticator = 0x7de4842ae4ba90547c74ba72e1e192ff
03:43:30 radius,debug,packet State = 0xc1bb6d52c2be74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 244 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x40095b2678081b8774342676fbaee23e
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c2be74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x020500061900
03:43:30 radius,debug,packet Message-Authenticator = 0x3439a6b7907ae3ad64469ba8c9418875
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:30 radius,debug,packet received Access-Challenge with id 244 from 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x6e107f2c7896cbea1ef63db70fe5729f
03:43:30 radius,debug,packet EAP-Message = 0x010602201900d4148a8f1519b5dec1a8
03:43:30 radius,debug,packet 9df1d65bc3da36deed62aaceeb196ed3
03:43:30 radius,debug,packet e1160ac30ec81dc36ef342890d601659
03:43:30 radius,debug,packet 69ad4bc1864666075d88070b71892294
03:43:30 radius,debug,packet 6a1b036c0b2a4e9e633e959dab43748e
03:43:30 radius,debug,packet 1a431e859075af294d1eeecfdc5329ba
03:43:30 radius,debug,packet 3f1def5eb0b8cfac28033b42f7c5daa2
03:43:30 radius,debug,packet b3ced2990bef73f874a4a39ca618ad8b
03:43:30 radius,debug,packet 2a7bb067046b4035fd57686e4f9bc054
03:43:30 radius,debug,packet 589f566405a29fa2ac2574e8f0d8f41b
03:43:30 radius,debug,packet 8091abb76ad7b2c19c26e2f509a94b37
03:43:30 radius,debug,packet 3692e3cd6eb57c3ef6d32c85eea5f645
03:43:30 radius,debug,packet 163d1df66a5a16160301014b0c000147
03:43:30 radius,debug,packet 03001741046b29323946fbe64d84d895
03:43:30 radius,debug,packet 2e9dc7c1c7f7496e7f60307011d19a41
03:43:30 radius,debug,packet 10b8e5af781c585bf552a5e2b8
03:43:30 radius,debug,packet EAP-Message = 0x5042c817d157f7af7542d05f0b8d6c8e
03:43:30 radius,debug,packet b1c521263928743601000d636f028759
03:43:30 radius,debug,packet dee622ef9dc897aebcd1974cf9ac6fa0
03:43:30 radius,debug,packet 9495d72c51134500fb7c50834a448378
03:43:30 radius,debug,packet ab721d00164f52f62e47bff6a97e7fb4
03:43:30 radius,debug,packet 5be9fe618d072c395496ad57a2510dde
03:43:30 radius,debug,packet fa2c65ad7394f26fde2e681eb525e178
03:43:30 radius,debug,packet 95c2b322a5f76e1fb46e7f3583c8733f
03:43:30 radius,debug,packet 1d1538426d3ad1d3bedb82a2177c4ddb
03:43:30 radius,debug,packet 1b52745098bbe9c8500b756d4f25213b
03:43:30 radius,debug,packet a8f707ab1033b7a7e745d7a2fb9f8d3e
03:43:30 radius,debug,packet 1636d06c5a1544ab7ab50180d83c4834
03:43:30 radius,debug,packet f8194bd89743c017aa1bf3e45688a7f6
03:43:30 radius,debug,packet 9c9418a1f207d0387589b0126772651d
03:43:30 radius,debug,packet aad88196a297a25e92566a31b37136b5
03:43:30 radius,debug,packet 074b89851407ff9278f16fa94e
03:43:30 radius,debug,packet EAP-Message = 0x0701d435a5c750ceba1dcefd752a00c0
03:43:30 radius,debug,packet f2b4a6b4c319ec6cd25acb096e160301
03:43:30 radius,debug,packet 00040e000000
03:43:30 radius,debug,packet Message-Authenticator = 0x0e5fa06e6f3e4bc5aeae95491d2339c7
03:43:30 radius,debug,packet State = 0xc1bb6d52c5bd74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 245 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x6cfca301bf3c86cb691c53f919b1641b
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c5bd74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x02060090198000000086160301004610
03:43:30 radius,debug,packet 000042410430e6273200b886f6ec0784
03:43:30 radius,debug,packet 25238bddb09e5a05f24d5263d64286d1
03:43:30 radius,debug,packet 5149e61f564a200a05561851b376c88b
03:43:30 radius,debug,packet 25289660ea8059f875b9fcdd648d759d
03:43:30 radius,debug,packet e86a49d00f1403010001011603010030
03:43:30 radius,debug,packet 08112980457c2cafde104639f365e45f
03:43:30 radius,debug,packet e165092deeb415889ffb607ce1c853b0
03:43:30 radius,debug,packet 5b369574a185abb76b64b57c77778812
03:43:30 radius,debug,packet Message-Authenticator = 0xa7f26a31454a4a8102059a620db9d7a4
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:30 radius,debug,packet received Access-Challenge with id 245 from 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x11c9b338b5b8a55ae4cc213c759b8651
03:43:30 radius,debug,packet EAP-Message = 0x01070041190014030100010116030100
03:43:30 radius,debug,packet 30ab13238f6949f5a033f0abfdf72c16
03:43:30 radius,debug,packet d7ed93183a0b3fd0cde3f0aa7a2ccbc0
03:43:30 radius,debug,packet 6920741721c65b97f6b6ae85c2389e4a
03:43:30 radius,debug,packet 29
03:43:30 radius,debug,packet Message-Authenticator = 0xdc1303f82a8ca43b3e5b28e51448fb61
03:43:30 radius,debug,packet State = 0xc1bb6d52c4bc74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 246 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0xd3fe71a95fb573e4eb38665e147fa2ff
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c4bc74cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x020700061900
03:43:30 radius,debug,packet Message-Authenticator = 0x42565d255007119d0d122fc339b11c5f
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:30 radius,debug,packet received Access-Challenge with id 246 from 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0xb7156d23a14fb3ae7b59c915471ce374
03:43:30 radius,debug,packet EAP-Message = 0x0108002b19001703010020de01b1062f
03:43:30 radius,debug,packet f6496a0b2abd347516233c95eb1da09f
03:43:30 radius,debug,packet baa8ebee7480220fbeaea3
03:43:30 radius,debug,packet Message-Authenticator = 0xeb9035b30d5db51370d4db090efc0a14
03:43:30 radius,debug,packet State = 0xc1bb6d52c7b374cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 247 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0xbdde72c34fca83528dc0f37782401217
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c7b374cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x0208003b190017030100300a794debdc
03:43:30 radius,debug,packet 99066c0fc331caeaf6999c8f08950009
03:43:30 radius,debug,packet 7012607d9358bdfad6ee436988be48e8
03:43:30 radius,debug,packet 3f2f3c6489f842595a7d18
03:43:30 radius,debug,packet Message-Authenticator = 0x64893d2cc79fa21c5c028aa5fea56d02
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:30 radius,debug,packet received Access-Challenge with id 247 from 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x06d8207876f37db619e03909fc4dd408
03:43:30 radius,debug,packet EAP-Message = 0x0109004b19001703010040b821a243d0
03:43:30 radius,debug,packet 00f9af78e277fafe6614826076c42304
03:43:30 radius,debug,packet 3af72fdee82dc61f23ffcefb4cc297fa
03:43:30 radius,debug,packet a1c045adad54f58e0b0244221158db84
03:43:30 radius,debug,packet 08ce7c0d1f5f22ea0b977c
03:43:30 radius,debug,packet Message-Authenticator = 0xaf772a1ffdac5a40cd413d7fe0bca318
03:43:30 radius,debug,packet State = 0xc1bb6d52c6b274cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 248 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0x795ce5a5d40a4aa8a5d32a65f30a55f0
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c6b274cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x0209006b190017030100606ae42580bb
03:43:30 radius,debug,packet 106d1207ea2ca18b4a47de3dda25a8b4
03:43:30 radius,debug,packet 7f2623031a820569ac6b81843839da0b
03:43:30 radius,debug,packet 4d39df58f34818e59ac92969c2845b29
03:43:30 radius,debug,packet 30c047f9449df5fda29433423bad09b2
03:43:30 radius,debug,packet dda17e5bbc88aad62fd6c42de59264aa
03:43:30 radius,debug,packet c0985d527e6568936d3895
03:43:30 radius,debug,packet Message-Authenticator = 0xe772f73f80de45f48c1f69125e7585b6
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:30 radius,debug,packet received Access-Challenge with id 248 from 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0xf7ab606dd0e2d7d6afe3b2ceee73831d
03:43:30 radius,debug,packet EAP-Message = 0x010a005b1900170301005041bd8fac56
03:43:30 radius,debug,packet 3a205f6c6c3511a79107e75a4b55fca1
03:43:30 radius,debug,packet ffda4420bd15d26abcc1d1b44a207667
03:43:30 radius,debug,packet c1c3674e9b6e0a678b9016a55701f40f
03:43:30 radius,debug,packet 4581278312e0365400e56f46593eb609
03:43:30 radius,debug,packet fe69694300d5728bf0ad9b
03:43:30 radius,debug,packet Message-Authenticator = 0xa288bc4f6d4aa9b7318f331abcb8d914
03:43:30 radius,debug,packet State = 0xc1bb6d52c9b174cd71f70b1b63d2de6d
03:43:30 radius,debug,packet sending Access-Request with id 249 to 198.51.100.34:1812
03:43:30 radius,debug,packet Signature = 0xf2f63fc37d4b619d68315ba38d833a18
03:43:30 radius,debug,packet Service-Type = 2
03:43:30 radius,debug,packet Framed-MTU = 1400
03:43:30 radius,debug,packet User-Name = "huber@maier.de"
03:43:30 radius,debug,packet State = 0xc1bb6d52c9b174cd71f70b1b63d2de6d
03:43:30 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:30 radius,debug,packet NAS-Port-Type = 19
03:43:30 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:30 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:30 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:30 radius,debug,packet EAP-Message = 0x020a002b19001703010020b020e7d404
03:43:30 radius,debug,packet 5a294752e394084ae591e79404fa60cb
03:43:30 radius,debug,packet fed40fe1070d2a88dec862
03:43:30 radius,debug,packet Message-Authenticator = 0x49345cb43866a619c1e3508e50e60ee6
03:43:30 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:30 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:31 radius,debug,packet received Access-Challenge with id 249 from 198.51.100.34:1812
03:43:31 radius,debug,packet Signature = 0x740450c839ce3f9e6f091a0072b1e31f
03:43:31 radius,debug,packet EAP-Message = 0x010b002b190017030100200b748b0dde
03:43:31 radius,debug,packet 6486bda29a6968c2b6be0da9452c69ae
03:43:31 radius,debug,packet d819e0999c6ba0296b38ec
03:43:31 radius,debug,packet Message-Authenticator = 0x0e7fef057396a517b57a691fdb55002f
03:43:31 radius,debug,packet State = 0xc1bb6d52c8b074cd71f70b1b63d2de6d
03:43:31 radius,debug,packet sending Access-Request with id 250 to 198.51.100.34:1812
03:43:31 radius,debug,packet Signature = 0x9de071e290e6770583f664e5da630faf
03:43:31 radius,debug,packet Service-Type = 2
03:43:31 radius,debug,packet Framed-MTU = 1400
03:43:31 radius,debug,packet User-Name = "huber@maier.de"
03:43:31 radius,debug,packet State = 0xc1bb6d52c8b074cd71f70b1b63d2de6d
03:43:31 radius,debug,packet NAS-Port-Id = "CAP-6C3B6B7695E3-1-1"
03:43:31 radius,debug,packet NAS-Port-Type = 19
03:43:31 radius,debug,packet Acct-Session-Id = "8210066c"
03:43:31 radius,debug,packet Calling-Station-Id = "A0-88-B4-D7-58-A4"
03:43:31 radius,debug,packet Called-Station-Id = "6E-3B-6B-76-95-E9:WIRELESS"
03:43:31 radius,debug,packet EAP-Message = 0x020b002b19001703010020ac6a7c9674
03:43:31 radius,debug,packet b779295b536433c77b125c40b8b554b4
03:43:31 radius,debug,packet 1e3fd187c8080acb970712
03:43:31 radius,debug,packet Message-Authenticator = 0xd66e4bbef81b461042c960c5d1141ca3
03:43:31 radius,debug,packet NAS-Identifier = "CAPsMAN"
03:43:31 radius,debug,packet NAS-IP-Address = 198.51.100.33
03:43:31 radius,debug,packet received Access-Accept with id 250 from 198.51.100.34:1812
03:43:31 radius,debug,packet Signature = 0xdb096f77bd316900fd55c4b5149116d0
03:43:31 radius,debug,packet MS-MPPE-Recv-Key = 0xb76dcd6498d849a10bea3e3e3131697f
03:43:31 radius,debug,packet 8504f1f8c3f691c683bbf93156b4baa9
03:43:31 radius,debug,packet eb1df591c88961cc33627132992dd4ec
03:43:31 radius,debug,packet 3966
03:43:31 radius,debug,packet MS-MPPE-Send-Key = 0xbb6aeb5c1b7fbd84ff9ad79a118e1e63
03:43:31 radius,debug,packet aba7980fd3dc551cad845c90e55b0462
03:43:31 radius,debug,packet ca99e0d3407151bb2f88de83f18c635d
03:43:31 radius,debug,packet 744d
03:43:31 radius,debug,packet EAP-Message = 0x030b0004
03:43:31 radius,debug,packet Message-Authenticator = 0xd7fedea48e69afe161343275a791b834
03:43:31 radius,debug,packet User-Name = "huber@maier.de"
well, after all changeing… user is till on VLAN 1
Get that working first, and then worry about the attributes that’s being sent after the EAP negotiation has completed.
