I have a network that the basic layout is:
I have an Rb2011 router installed on a machine and to connect to the wifi network I am using a moxa radio awk-4131 as a client. Then he connects to the network with the Ap mikrotik in Layer 2 until he reaches another Rb2011 to follow within the main network.
The information traffic is working normally, the problem is that the Router Rb2011 installed on the machine when it goes up in the network it has the same MAC of the Moxa radio that is the client.
Does anyone know what I have to do, for the Router on the machine to go up on the network and remain with the same MAC?
Which RB2011 are you talking about? The one beyond wireless bridge?
The problem is wireless bridge, 802.11 standard does not standardize it. Every vendor came up with (mostly incompatible) solution which only works as intended when both ends of wireless hop are by same vendor. In your case they’re moxa an mikrotik. There are workarounds which make mixed-vendor solution to work somehow, but not entirely transparently. Read about mikrotik options in this article.
Which RB2011 are you talking about? The one beyond wireless bridge?
Yes, You have one R2011Ui.
Do you think there is some configuration on the router behind the wirelles bridge, which can generate transparency and prevent the rest of the network from seeing this MAC duplicity?
