Idea for Winbox - describe subnet in winbox

RouterOS General
1

How do you like this idea?

  • Not usefull feature.
  • I am not interesting about this feature.
  • It coud be verry usefull feature.
0 voters

I like right described network and my idea is add a feaures to winbox for better description network, which is behind The router. For example if i upload a picture to the routerboard with name structure.png it coud be showed as background image on winbox as is on attachment. What do you thing about it. Current dark-gray backroud is not usefull. This can be verry usefull on hudge or home network. What do you thing about it, MT technics?
Background image can be switched on or off by checkbox on the top as HIDE PASSWORDS 8)

2

I’m thinking our The Dude application,
http://www.mikrotik.com/thedude.php
allows you to make something similar.

Draw entire network there, when need Winbox to any device to tune specific settings, right mouse click on the device “Tools” —> “Winbox”, tune settings when network structure is behind your eyes in The Dude.
