Hi Guys
well i have some problem with data routing on mikrotikOS 2.9.51
please take a look my network topology bellow …
and.my.configuration…
ip address pr
**Flags: X - disabled, I - invalid, D - dynamic
ADDRESS NETWORK BROADCAST INTERFACE
0 192.168.10.1/24 192.168.10.0 192.168.10.255 proxy
1 10.111.111.3/24 10.111.111.0 10.111.111.255 Local
2 192.168.1.1/24 192.168.1.0 192.168.1.255 internet1**ip firewall mangle
15 ;;; pcq-128-TESTING-1st
chain=forward src-address=!10.111.111.2 routing-mark=main action=mark-connection new-connection-mark=download128k passthrough=no
16 chain=forward src-address=!10.111.111.2 routing-mark=main action=mark-connection new-connection-mark=upload32k passthrough=no
17 chain=forward src-address=!10.111.111.3 routing-mark=main action=mark-connection new-connection-mark=download128k passthrough=no
18 chain=forward src-address=!10.111.111.3 routing-mark=main action=mark-connection new-connection-mark=upload32k passthrough=no
19 chain=prerouting connection-mark=download128k action=mark-packet new-packet-mark=down-128-k passthrough=yes
20 chain=prerouting connection-mark=upload32k action=mark-packet new-packet-mark=up-32-k passthrough=yes
…
24 chain=prerouting connection-state=new action=mark-connection new-connection-mark=LocalinK passthrough=yes
25 chain=prerouting in-interface=Local src-address=!10.111.111.2 dst-address=!10.111.111.3 connection-mark=LocalinK action=mark-routing
new-routing-mark=LOCALink passthrough=no
26 chain=prerouting in-interface=Local src-address=!10.111.111.3 dst-address=!10.111.111.3 action=mark-routing new-routing-mark=LOCALink passthrough=no
27 chain=prerouting in-interface=Local connection-mark=LocalinK action=mark-packet new-packet-mark=TEST-LOCAL passthrough=yes >#### queue tree pr ####
2 name=“LOCAL” parent=Local packet-mark=TEST-LOCAL limit-at=0 queue=default priority=1 max-limit=0 burst-limit=0 burst-threshold=0 burst-time=0s
3 name=“128K–DOWN” parent=global-in packet-mark=download128k limit-at=0 queue=pcq128k-DOWN priority=1 max-limit=128000 burst-limit=0 burst-threshold=0
burst-time=0s4 name=“128K–UP” parent=global-out packet-mark=up-32-k limit-at=0 queue=pcq128k-UP priority=1 max-limit=32000 burst-limit=0 burst-threshold=0 burst-time=0s
\queue type
set default name=“default” kind=pfifo pfifo-limit=50
set ethernet-default name=“ethernet-default” kind=pfifo pfifo-limit=50
set wireless-default name=“wireless-default” kind=sfq sfq-perturb=5 sfq-allot=1514
set synchronous-default name=“synchronous-default” kind=red red-limit=60 red-min-threshold=10 red-max-threshold=50 red-burst=20 red-avg-packet=1000
set hotspot-default name=“hotspot-default” kind=sfq sfq-perturb=5 sfq-allot=1514
add name=“pcq128k-DOWN” kind=pcq pcq-rate=0 pcq-limit=50 pcq-classifier=dst-address pcq-total-limit=2000
add name=“pcq128k-UP” kind=pcq pcq-rate=0 pcq-limit=50 pcq-classifier=src-address pcq-total-limit=2000
add name=“default-small” kind=pfifo pfifo-limit=10 >
====================================================================================================
now.I.have.some.question`s.regarding.my.network.topology and my.network.configuration=
1# I.have.2.client.that.always.update.their.database.their.ip.is=10.111.111.2 and 10.111.111.3, so.I.need.your.help.to.solve.my.problem.
HOW.to.route/mangle.those.ip.in.LOCAL.without.get.limited.by.PCQ.QUEUE.in.my
network.-they.use.some.program.databse.so.they.have.to.update.their.database.from.10.111.111.2 to. 10.111.111.3
2# I.have.made.configuration.(please.see.on.ip firewall mangle and queue but.untested.yet.
because.the.work.time.is.over.and.i.still.don`t.get.success.before.work.time.is.end
I.hope.you.get.my.point.even.just.little…o_O
any answer,comment or suggestion will be so helpfull
Thanks so much
