Hello All MIkrotik.com Residents
Introduce me from Indonesia
because the web for the proxy forum in our country is dead (forummikrotik.com), then let me ask a question in this forum
Previously, I apologized if my use of language seemed bad or harsh, because I used Google translate from Indonesian to English
Alright, let’s start
Device
-X86 Version-6.49.8 Lv=6
#Interfaces
Ether1 = ISP1
Ether2 = ISP2
Ether3 = LAN1
Ether4 =VLAN10
#IP
-IP ISP1 = 10.100.101.2/30 , gateway = 10.100.101.1
-IP ISP2 = 192.168.1.73/24 , gateway = 192.168.1.1
-LAN-1 = 172.16.10.1/24
-VLAN10-1 = 10.10.10.1/23
-VlAN10-2 =20.20.20.1/24
#DNS
-8.8.8.8
#NAT
- Masquareade for ether2
#Monitoring
-The dude
Previously I used ECMP Load Balancing, and it ran successfully… it can PING between VLANs and LANs
until later on there was a problem, namely all DVRs in all places could not be accessed from outside the network or the internet
then changed to using ISP1 for VLAN10-1 and ISP2 for LAN-1 and VLAN10-2, with the result that the DVR can be accessed from outside the network
then there is a problem here that is
between LAN-1 cannot PING to VLAN10-1 and VLAN10-2 (or vice versa), because of this monitoring becomes inactive
My problem is
how IP between LAN-1 and VLAN can communicate or in PING ?
I have tried for several NAT Rules and it still doesn’t work for PING
for suggestions and criticism, I wait from the members here
Thank You
