RB912UAG-2HPnD with ME909u-521

RouterOS General
1

Hey guys,

This is my first time i’m using a LTE card, so i don’t know a lot about it.
But i got this thing working, but the internet is very slow (under 1 mb).
I’m running version 6.22
I’m getting an IP from the ISP and can connect from the outside

Does anyone has an idea what the problem can be?
[admin@MikroTik] > interface lte info lte1
status: call in progress
pin-status: no password required
functionality: full
manufacturer: Huawei Technologies Co., Ltd.
model: ME909u-521
revision: 11.234.77.00.00
current-operator: NL KPN KPN
current-cellid: 2995469
access-technology: Evolved 3G (LTE)
signal-strengh: -79 dBm
frame-error-rate: n/a
imei: 860461024084645
imsi: 204086597938089
rssi: -79dBm
rsrp: -109dBm
rsrq: -13dB
sinr: -1dB

Dennis

2

Try to check if the wifi antennas are not too close to the LTE antennas. Also try to change the position of the LTE antennas to get better LTE signal.

3

I don’t use the wifi, so i disabled it.

I try to change the position but i can’t get a better signal.
Should i try a other antenna?

4

I don’t use the WIFI so i disabled the interface.

I try to change the position but i can’t get a better signal. When i use my 4G dongle on the laptop i’n getting 20mb, so the signal should be ok on that spot.
Should i try an other 4g antenna?
