Really strange IPsec Mikrotik issue

RouterOS Beginner Basics
1

Hello everyone, I just noticed one issue that I cannot even name properly but I´ll try to explain.

Situation one:
I have an Site-to-Site IPsec tunnel working fine, two Cisco routers, two networks:
192.168.1.0/24 and 192.168.18.0/24
Both ciscos running at 192.168.1.1 and 192.168.18.1
Traffic is passing fine, everything works.

IF from server 1 with IP 192.168.1.250 (SRC) I open another server with IP 192.168.18.250 (DST) , on destination server I see remote connection from 192.168.1.250:xxxxx to local 192.168.18.250:443

IF I mirror the sides, i get exactly opposite behaviour (192.168.1.250:443 as destination server sees request from 192.168.18.250:xxxxx)

Situation two with MikroTik

Lets just say I replace Cisco on the 18.0/24 subnet, what happens is this:
IF from server 1 with IP 192.168.1.250 (SRC) I open another server with IP 192.168.18.250 (DST) , on destination server I see remote connection from 192.168.18.1:xxxxx to local 192.168.18.250:443
On the remote server with Cisco I see 192.168.1.250:xxxxx > 192.168.18.250:443

xxxxx is some random outgoing port.

Why on the Mikrotik side I always see traffic coming from gateway address and not directly from source? But with two cheap SMB Ciscos I see source and destination addresses just fine?
Why is this happening? Is this some kind of NAT or something ? Routing issue?

Thank you very much for help

2

So I just realized this also happens with Intervlan routing, what the heck is going on? Why is this happening?
The text in the red boxes is what Windows/Linux is reporting, basically everything is seen as traffic originating from gateway itself, why?? I never experienced this kind of behaviour on Cisco switches or routers, they always showed me where is traffic originating from, Mikrotik is hiding everything behind itself, even on VPNs.

3

We need configuration so we can help. Blind guess is like you assumed - NAT, but there could be also a lot of other things.

4

Check your srcnat rules. It can’t be unlimited masquerade as usual, because it would also break the tunnel. But it does look like there’s srcnat for traffic going to LAN.

5

Thank you guys for pointing me to the right direction, there were two rules

ip firewall nat chain=srcnat action=masquerade dst-address=192.168.18.0/24
ip firewall nat chain=srcnat action=masquerade dst-address=192.168.19.0/24

So basically everything that was natted came through gateway, since i have servers only on 18.0/24 network, i deleted the second rule and added src-address rule to create hairpin nat originating from 18.0/24 to 18.0/24

Everything is ok now.

Thank you both
