Work with file txt

RouterOS Scripting
1

Hi,
I’ll try to make a file and edit him from a script.

The situation is:
for all lease on dhcp server lease make it static and write a file with ip and mac etc etc..


how can I update the file without losing the previous file?

thank you so much

2

Here you find the script that converts dynamic DHCP to static automatically.
http://forum.mikrotik.com/t/dhcp-automatic-dynamic-to-static/129147/1

Instead of writing it to a file, I send it out as syslog to Splunk.
This way I can analyze what it going on and when later.

Look at my signature for logging Mikrotik using Splunk

3

thank you jotne,
but i need only associate ip-mac-caseID (CALEA) in one file and update him.
no more nor less.
thank

4

Script should do?

Can you post an example line of what you see int the log that you need?

Here is an example of DHCP request with debug enabled:

dhcp,debug,packet MikroTik: DHCP-vlan20-Guest received request with id 3566786364 from 0.0.0.0
dhcp,debug,packet MikroTik:     secs = 3
dhcp,debug,packet MikroTik:     ciaddr = 0.0.0.0
dhcp,debug,packet MikroTik:     chaddr = 6C:8D:C1:03:xxxx
dhcp,debug,packet MikroTik:     Msg-Type = request
dhcp,debug,packet MikroTik:     Parameter-List = Subnet-Mask,Classless-Route,Router,Domain-Server,Domain-Name,Domain-Search,Auto-Proxy-Config
dhcp,debug,packet MikroTik:     Max-DHCP-Message-Size = 1500
dhcp,debug,packet MikroTik:     Client-Id = 01-6C-8D-C1-03-xxxx
dhcp,debug,packet MikroTik:     Address-Request = 10.10.20.184
dhcp,debug,packet MikroTik:     Server-Id = 10.10.20.1
dhcp,debug,packet MikroTik:     Host-Name = "iPhone"
dhcp,info MikroTik: DHCP-vlan20-Guest assigned 10.10.20.184 to 6C:8D:C1:03:xxxx
dhcp,debug,packet MikroTik: DHCP-vlan20-Guest sending ack with id 3566786364 to 10.10.20.184
dhcp,debug,packet MikroTik:     ciaddr = 0.0.0.0
dhcp,debug,packet MikroTik:     yiaddr = 10.10.20.184
dhcp,debug,packet MikroTik:     siaddr = 10.10.20.1
dhcp,debug,packet MikroTik:     chaddr = 6C:8D:C1:03:xxxx
dhcp,debug,packet MikroTik:     Msg-Type = ack
dhcp,debug,packet MikroTik:     Server-Id = 10.10.20.1
dhcp,debug,packet MikroTik:     Address-Time = 86400
dhcp,debug,packet MikroTik:     Subnet-Mask = 255.255.255.0
dhcp,debug,packet MikroTik:     Router = 10.10.20.1
dhcp,debug,packet MikroTik:     Domain-Server = 10.10.10.1
5

Hi,
The script should do :

  • Make Static - do
  • other - do
  • make and update the file with mac - ip - case-id (CALEA) - not to

no more

i need only the command for make a file and update him without losing the previous saved.
thank

6

Can you post a log line that does contain?
Do you see that from my log line above?

mac - ip - case-id (CALEA)

I do not see what this is.

7

ok, this is the code:

:global IProap 192.168.88.1;

:global caseID 10;

:global interceptPort 5000;

:global nameFile "Traffic_assoc.txt";

:global ContentsFile;

:global IPint;

:foreach Lease in=[ / ip dhcp-server lease find where dynamic=yes ] do={
  :local MacAddress [ / ip dhcp-server lease get $Lease mac-address ];
  :set IPint [/ip dhcp-server lease get value-name=address number=$Lease;];
  /ip dhcp-server lease make-static numbers=$Lease;
  /tool calea add action=pcap intercept-port=$interceptPort case-id=$caseID intercept-ip=$IProap;
  /ip firewall calea add action=sniff-pc chain=forward sniff-id=$caseID sniff-target=$IProap sniff-target-port=$interceptPort src-address=$IPint;
  /ip firewall calea add action=sniff-pc chain=forward sniff-id=$caseID sniff-target=$IProap sniff-target-port=$interceptPort dst-address=$IPint;
  :set ContentsFile "$MacAddress - $IPint - $caseID";
  /file print file=$nameFile;
  /file set $nameFile contents=([get $nameFile contents] . $ContentsFile);
  :set caseID ($caseID + 1);
  :set interceptPort ($interceptPort + 1);
}

the target of the script is, for all client connected on LAN make it static and sniff traffic for all.
for this scope use the extra pack CALEA.
i needed to make a file where associated MAC - IP - CASE-ID for distinct the target device.



8

Look at Splunk in my signature.

Here are what I do.
All DHCP->Static
Add DNS Name to host that I do now what is.

Then using account snapshot to get the traffic to Splunk.
In Splunk I have Dashboard that show me who are using how much. I can select one user and see that user over time.
See example one example here. This are just som part of the information I do get. DNS/Filter/Traffic/UPtime/DHCP/Resources ++++++

9

ok, but I don’t want to see the traffic consumer, I want to intercept the traffic and view where the guest browsing

10

And that I do get. All are in the logs:

script,info MikroTik: .id=*111;bytes=104;dst-address=35.164.108.188;packets=2;src-address=10.10.20.188;script=traffic
script,info MikroTik: .id=*110;bytes=11325;dst-address=37.247.52.130;packets=90;src-address=10.10.10.32;script=traffic
script,info MikroTik: .id=*10f;bytes=44638;dst-address=83.93.164.241;packets=410;src-address=10.10.10.50;script=traffic

Src_ip, dest_ip and bytes for all host, both out and inn.

11

ok jotne,
But for using Splunk, I need to make a server or client infrastructure.
this is a flash project for the convention of cyber security (ethical hacker convention), I need a little locale structure standalone when I can be powered with a battery pack.
make a sever o client is so much, the object is to make all with a single and standalone spot with a single Routerboard - LTE modem (KEY o SIM) and external storage (external hard drive) for store the data.

All for training the guest and make a fun lab.
