I am configuring VLANs for my network (VLAN 88 → home network, untagged / VLAN 10 → guest network, tagged / VLAN 20 → IoT network, tagged).
As mentioned in Bridge VLAN Filtering (https://help.mikrotik.com/docs/display/ROS/Bridging+and+Switching#BridgingandSwitching-BridgeVLANFiltering) -
“Make sure you have added all needed interfaces to the bridge VLAN table when using bridge VLAN filtering. For routing functions to work properly on the same device through ports that use bridge VLAN filtering, you will need to allow access to the bridge interface (this automatically include a switch-cpu port when HW offloaded vlan-filtering is used, e.g. on CRS3xx series switches), this can be done by adding the bridge interface itself to the VLAN table, for tagged traffic you will need to add the bridge interface as a tagged port and create a VLAN interface on the bridge interface. Examples can be found in the inter-VLAN routing and Management port sections.”
Also said that “Optional step is to set frame-types=admit-only-vlan-tagged on the bridge interface in order to disable the default untagged VLAN 1 (pvid=1).”
So I have also this:
/interface bridge set bridge1 frame-types=admit-only-vlan-tagged
But also said that “When allowing access to the CPU, you are allowing access from a certain port to the actual router/switch, this is not always desirable. Make sure you implement proper firewall filter rules to secure your device when access to the CPU is allowed from a certain VLAN ID and port, use firewall filter rules to allow access to only certain services.”
As i understand now i have access to CPU from all 3 VLANS. I want only access to device from VLAN88 - so what firewall rules I need for that ?
and you have appropriate IP addresses set on all 3 vlan interfaces.
Now device will route traffic between the 3 subnets. If you want to block traffic between some pair of devices, then you need a firewall rule which blocks that traffic.
Default firewall setup uses LAN interface list and WAN interface list. And uses last rule which drops all traffic from WAN which is not DST-NATed. Which makes all the rest allowed (doesn’t matter if interface is part of LAN interface list). Adding a rule (in dedault firewall setup can even be the last rule)
will block connections, started in VLAN 10 and targeting destinations in VLAN 88. But won’t block connections in the opposite direction … which is a feature. If you want to block connections in the other direction, you need a similar rule, but reversed in- and out-interface.
What the highlited quote is telling is, that devices in those subnets will have also access to services of router itself, e.g. DHCP server and DNS (probably this is desired), but also ssh and webfig (which may be fine for certain subnet but not for the rest of subnets). To regulate this accessibility, you have to add appropriate firewall rules for chain=input.
The way firewall rules have to be adapted very much depends on how your network looks like and what kind of connectivity is needed. ROS is very flexible as to what admin can do, but this also means that admin better knows what (s)he is doing …
What most do is simply have a rule at the end of the forward chain for example
add chain=forward action=drop comment=Drop all Else
Thus unless you have rules above this allowing traffic, EVERYTHING else is blocked.
So typcially one has
allow LAN interface list to WAN interface list for internet
allow admin to all subnets
allow LAN interface list to shared printer
etc…
does it mean that access to CPU can be made from vlan 10 or vlan 20 - those 2 vlans didn’t need to communicate with vlan 88 to access bridge - or not? What sense in blocking subnets from access to each other to prevent them from access to device- or somewhere in settings does exist some parameter that define address of device is only 192.168.88.1 and not 182.168.10.1(or 192.168.20.1) ? - sorry for maybe stupid question …
Traffic flow is directed by the /interface bridge ports and /interface bridge vlans.
In other words they instruct where VLANX goes in and out of ports and whether or not its flowing out of a port tagged or untagged and whether or not its tagged coming into a port etc..
The firewall rules are there to allow one to poke holes in the vlans so to speak, so that for example VLANX can use a printer on VLANY at Layer 3.
Separation between vlans is automatic due to L2 separation, firewall rules prevent the router from routing between vlans.
So will it works if i make interface list “allowed_to_router” and place only VLAN88 to that list and in rule instead of src-address-list place in-interface-list ?
…
