Wireless interface - Slave

psm · July 7, 2010, 8:25pm

Hello

Today evening i saw “S” flag on one of my wireless interfaces.

Can anyone tell me what it means ?

As you can see below, interface works in AP bridge mode and isn’t ns2 or bonding slave.
Thanks for help

Regards,

adrianatkins · July 7, 2010, 10:20pm

A Bug maybe ?

Did it stop saying ‘RS’ when you quit Winbox and restarted ?

Did it stop saying ‘RS’ after you rebooted the mikrotik ?

maximan · July 8, 2010, 6:21pm

I guess

R = running
S = Slave

On the screenshot appear “slave” on black letters

M.

psm · July 8, 2010, 6:34pm

I quit Winbox and log in again - still slave.
After reboot … still slave…

So… maybe it’s a bug (v3.30)

Yes. I know, it’s (S)lave and (R)unning… but i don’t know why it’s (S)lave

Anyway… thanks for trying

Regards

adrianatkins · July 8, 2010, 9:10pm

Well, Up the Firmware revision and see what happens.

Actually, before doing that, just try these things (if you have time) :-

change the MAC of the second radio to 10 at the start instead of 00.
change the SSID of the second card to be X… (i.e. start with an X)

reboot when you change something.

I’ll be intrigued (and maybe a bit scared) to find that #1 stops it saying ‘Slave’

maximan · July 13, 2010, 3:09pm

export /interface wireless

Yes. I know, it’s (S)lave and (R)unning… but i don’t know why it’s (S)lave >

Anyway… thanks for trying >

Regards

M.

imaljko4 · January 17, 2014, 12:26am

I have the same question/problem.

My wireless card is set to ap-bridge mode ( no wds…etc.)
But when i check my interface it says “RS” (R-running, S-slave)

Dont understand why my Wireless is marked as slave.

RouterOS V6.7, RB751U-2HND

Thanks

npero · January 17, 2014, 7:09am

Because your interfaces is in bridge, that’s makes S.
Check Bridge/Ports you interface is add there.

Lakis · January 17, 2014, 7:55am

yes if the protocol mode is in rstp

npero · January 17, 2014, 8:33am

Why need to to use rstp ? On all my devices protocol is none and also have S in bridge interface, of course we are talking about version 6.x ? In older version is different.

imaljko4 · January 17, 2014, 10:19am

Yes, my wireless interface is added to the bridge.
But my Bridge protocol mode is set to “none” (No rstp).

(Ok. so probably as soon as it is in bridge mode, it ads S-slave to the interface)

Thanks

npero · January 17, 2014, 11:44am

Yes because you are using v6.x.

Lakis · January 17, 2014, 7:13pm

sorry I’ve made mistake in 6.x is different
I also don’t use rstp I run in some problems with it, long story.
